| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_118T01_9000002962_19899cztM0_level2.evt | modeM0/AS1T03_118T01_9000002962_19899cztM0_level2_quad_clean.evt |
| Size (bytes) | 491,667,840 | 65,796,480 |
| Size | 468.9 MB | 62.7 MB |
| Events in quadrant A | 3,316,600 | 396,166 |
| Events in quadrant B | 3,426,881 | 395,908 |
| Events in quadrant C | 3,301,063 | 375,164 |
| Events in quadrant D | 4,399,752 | 366,644 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13980 | 2 |
| B | 0 | 14347 | 2 |
| C | 0 | 13867 | 2 |
| D | 0 | 17304 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6575 | 63 | 0.958175% |
| B | 6575 | 76 | 1.155894% |
| C | 6575 | 72 | 1.095057% |
| D | 6575 | 254 | 3.863118% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7665 | 6575 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7665 | 6575 | 3 | 3 | 0.04% | 0.05% |  |
| C | 7665 | 6575 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7665 | 6575 | 210 | 210 | 2.74% | 3.19% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 40907 | 235.82 | 851 | 836 | 169.9 |
| A | 0 | 226 | 7465 | 39.01 | 851 | 836 | 169.9 |
| A | 3 | 137 | 6832 | 35.29 | 851 | 836 | 169.9 |
| B | 7 | 220 | 49732 | 305.62 | 843 | 823 | 160.0 |
| B | 0 | 230 | 20895 | 125.42 | 843 | 823 | 160.0 |
| B | 12 | 111 | 19042 | 113.85 | 843 | 823 | 160.0 |
| C | 14 | 238 | 127510 | 671.59 | 810 | 815 | 188.7 |
| C | 9 | 221 | 7745 | 36.73 | 810 | 815 | 188.7 |
| C | 7 | 220 | 6586 | 30.59 | 810 | 815 | 188.7 |
| D | 7 | 238 | 509427 | 2577.51 | 821 | 798 | 197.3 |
| D | 1 | 52 | 277288 | 1401.13 | 821 | 798 | 197.3 |
| D | 5 | 222 | 192484 | 971.38 | 821 | 798 | 197.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
