| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_064T01_9000002964_19919cztM0_level2.evt | modeM0/AS1A05_064T01_9000002964_19919cztM0_level2_quad_clean.evt |
| Size (bytes) | 825,200,640 | 102,216,960 |
| Size | 787.0 MB | 97.5 MB |
| Events in quadrant A | 2,957,700 | 750,327 |
| Events in quadrant B | 3,714,737 | 757,070 |
| Events in quadrant C | 6,240,908 | 717,239 |
| Events in quadrant D | 11,636,255 | 413,039 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13323 | 1 |
| B | 0 | 15396 | 1 |
| C | 0 | 23109 | 1 |
| D | 0 | 39066 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6543 | 16 | 0.244536% |
| B | 6543 | 112 | 1.711753% |
| C | 6543 | 699 | 10.683173% |
| D | 6543 | 3655 | 55.861226% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7563 | 6544 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7563 | 6543 | 20 | 20 | 0.26% | 0.31% |  |
| C | 7563 | 6543 | 229 | 229 | 3.03% | 3.50% |  |
| D | 7562 | 6542 | 3529 | 3529 | 46.67% | 53.94% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 226 | 6811 | 39.22 | 766 | 748 | 154.6 |
| A | 5 | 16 | 6325 | 36.08 | 766 | 748 | 154.6 |
| A | 3 | 137 | 5666 | 31.82 | 766 | 748 | 154.6 |
| B | 3 | 112 | 312719 | 2173.02 | 773 | 753 | 143.6 |
| B | 7 | 220 | 139791 | 968.48 | 773 | 753 | 143.6 |
| B | 4 | 216 | 59551 | 409.56 | 773 | 753 | 143.6 |
| C | 9 | 221 | 3065964 | 17997.67 | 732 | 736 | 170.3 |
| C | 4 | 254 | 144687 | 845.22 | 732 | 736 | 170.3 |
| C | 14 | 238 | 113298 | 660.91 | 732 | 736 | 170.3 |
| D | 12 | 218 | 4044001 | 33397.88 | 494 | 479 | 121.1 |
| D | 2 | 184 | 3822323 | 31566.91 | 494 | 479 | 121.1 |
| D | 7 | 38 | 1239159 | 10231.0 | 494 | 479 | 121.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
