| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_160T01_9000002970_19947cztM0_level2.evt | modeM0/AS1A05_160T01_9000002970_19947cztM0_level2_quad_clean.evt |
| Size (bytes) | 531,547,200 | 86,722,560 |
| Size | 506.9 MB | 82.7 MB |
| Events in quadrant A | 4,048,937 | 557,326 |
| Events in quadrant B | 3,637,090 | 564,259 |
| Events in quadrant C | 4,089,452 | 534,121 |
| Events in quadrant D | 3,897,207 | 532,644 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16114 | 2 |
| B | 0 | 14894 | 2 |
| C | 0 | 16286 | 2 |
| D | 0 | 15644 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23 | 0 |
| B | 0 | 24 | 0 |
| C | 0 | 24 | 0 |
| D | 0 | 24 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6268 | 344 | 5.488194% |
| B | 6268 | 155 | 2.472878% |
| C | 6268 | 285 | 4.546905% |
| D | 6267 | 213 | 3.398755% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7518 | 6268 | 190 | 190 | 2.53% | 3.03% |  |
| B | 7518 | 6268 | 26 | 26 | 0.35% | 0.41% |  |
| C | 7518 | 6268 | 79 | 79 | 1.05% | 1.26% |  |
| D | 7517 | 6267 | 119 | 119 | 1.58% | 1.90% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 238 | 785165 | 4650.3 | 848 | 833 | 168.7 |
| A | 0 | 226 | 7305 | 38.37 | 848 | 833 | 168.7 |
| A | 3 | 137 | 6337 | 32.63 | 848 | 833 | 168.7 |
| B | 7 | 220 | 145588 | 902.47 | 854 | 836 | 160.4 |
| B | 15 | 32 | 72179 | 444.79 | 854 | 836 | 160.4 |
| B | 0 | 197 | 49503 | 303.42 | 854 | 836 | 160.4 |
| C | 3 | 233 | 421792 | 2212.82 | 826 | 834 | 190.2 |
| C | 9 | 221 | 246602 | 1291.91 | 826 | 834 | 190.2 |
| C | 14 | 238 | 129022 | 673.84 | 826 | 834 | 190.2 |
| D | 1 | 52 | 694283 | 3394.21 | 840 | 818 | 204.3 |
| D | 2 | 234 | 31084 | 148.14 | 840 | 818 | 204.3 |
| D | 2 | 184 | 15069 | 69.75 | 840 | 818 | 204.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
