| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_082T09_9000002978_19979cztM0_level2.evt | modeM0/AS1A05_082T09_9000002978_19979cztM0_level2_quad_clean.evt |
| Size (bytes) | 901,486,080 | 86,834,880 |
| Size | 859.7 MB | 82.8 MB |
| Events in quadrant A | 14,858,401 | 174,566 |
| Events in quadrant B | 3,652,977 | 666,759 |
| Events in quadrant C | 4,669,094 | 634,407 |
| Events in quadrant D | 3,615,561 | 632,601 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 152 | 0 |
| B | 0 | 152 | 0 |
| C | 0 | 152 | 0 |
| D | 0 | 152 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 49261 | 7 |
| B | 0 | 15684 | 2 |
| C | 0 | 18907 | 2 |
| D | 0 | 15978 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7465 | 6139 | 82.237106% |
| B | 7465 | 50 | 0.669792% |
| C | 7465 | 145 | 1.942398% |
| D | 7466 | 35 | 0.468792% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8360 | 7465 | 4267 | 4267 | 51.04% | 57.16% |  |
| B | 8360 | 7466 | 9 | 9 | 0.11% | 0.12% |  |
| C | 8360 | 7467 | 31 | 31 | 0.37% | 0.42% |  |
| D | 8361 | 7468 | 15 | 15 | 0.18% | 0.20% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 238 | 13277589 | 203631.57 | 315 | 309 | 65.2 |
| A | 14 | 254 | 342692 | 5251.07 | 315 | 309 | 65.2 |
| A | 14 | 237 | 18644 | 281.2 | 315 | 309 | 65.2 |
| B | 7 | 220 | 61572 | 352.22 | 899 | 877 | 172.3 |
| B | 12 | 111 | 21132 | 117.54 | 899 | 877 | 172.3 |
| B | 4 | 171 | 20450 | 113.58 | 899 | 877 | 172.3 |
| C | 3 | 233 | 1026844 | 5037.09 | 867 | 872 | 203.7 |
| C | 14 | 238 | 133816 | 652.7 | 867 | 872 | 203.7 |
| C | 9 | 221 | 64386 | 311.83 | 867 | 872 | 203.7 |
| D | 1 | 52 | 224215 | 1048.07 | 880 | 855 | 213.1 |
| D | 2 | 234 | 31011 | 141.5 | 880 | 855 | 213.1 |
| D | 7 | 96 | 20269 | 91.1 | 880 | 855 | 213.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
