| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_022T08_9000002980_19984cztM0_level2.evt | modeM0/AS1A05_022T08_9000002980_19984cztM0_level2_quad_clean.evt |
| Size (bytes) | 613,396,800 | 76,150,080 |
| Size | 585.0 MB | 72.6 MB |
| Events in quadrant A | 6,003,024 | 453,797 |
| Events in quadrant B | 3,343,613 | 484,159 |
| Events in quadrant C | 3,656,617 | 455,305 |
| Events in quadrant D | 5,121,035 | 446,894 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22133 | 2 |
| B | 0 | 13939 | 2 |
| C | 0 | 15022 | 2 |
| D | 0 | 19771 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6673 | 1121 | 16.799041% |
| B | 6674 | 74 | 1.108780% |
| C | 6674 | 212 | 3.176506% |
| D | 6674 | 631 | 9.454600% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7658 | 6673 | 871 | 871 | 11.37% | 13.05% |  |
| B | 7659 | 6674 | 10 | 10 | 0.13% | 0.15% |  |
| C | 7658 | 6673 | 79 | 79 | 1.03% | 1.18% |  |
| D | 7659 | 6674 | 481 | 481 | 6.28% | 7.21% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 238 | 2977875 | 19137.63 | 774 | 759 | 155.6 |
| A | 14 | 254 | 44426 | 280.7 | 774 | 759 | 155.6 |
| A | 0 | 226 | 6567 | 37.34 | 774 | 759 | 155.6 |
| B | 7 | 220 | 57232 | 356.12 | 832 | 813 | 158.4 |
| B | 12 | 111 | 19253 | 116.39 | 832 | 813 | 158.4 |
| B | 11 | 111 | 16737 | 100.51 | 832 | 813 | 158.4 |
| C | 0 | 207 | 386843 | 2105.34 | 785 | 790 | 183.4 |
| C | 14 | 238 | 122046 | 661.27 | 785 | 790 | 183.4 |
| C | 3 | 233 | 73633 | 397.25 | 785 | 790 | 183.4 |
| D | 1 | 52 | 1524821 | 8097.53 | 776 | 753 | 188.2 |
| D | 12 | 218 | 454990 | 2413.41 | 776 | 753 | 188.2 |
| D | 13 | 104 | 94856 | 499.98 | 776 | 753 | 188.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
