| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_002T02_9000002982_20002cztM0_level2.evt | modeM0/AS1A06_002T02_9000002982_20002cztM0_level2_quad_clean.evt |
| Size (bytes) | 525,113,280 | 76,233,600 |
| Size | 500.8 MB | 72.7 MB |
| Events in quadrant A | 3,670,446 | 480,250 |
| Events in quadrant B | 3,691,157 | 482,303 |
| Events in quadrant C | 3,556,304 | 456,157 |
| Events in quadrant D | 4,555,566 | 447,582 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14951 | 2 |
| B | 0 | 15001 | 2 |
| C | 0 | 14520 | 2 |
| D | 0 | 17550 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6330 | 158 | 2.496051% |
| B | 6330 | 118 | 1.864139% |
| C | 6330 | 113 | 1.785150% |
| D | 6330 | 419 | 6.619273% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7565 | 6331 | 33 | 33 | 0.44% | 0.52% |  |
| B | 7565 | 6331 | 13 | 13 | 0.17% | 0.21% |  |
| C | 7565 | 6331 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7565 | 6331 | 234 | 234 | 3.09% | 3.70% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 238 | 187593 | 1073.87 | 881 | 867 | 173.9 |
| A | 5 | 16 | 93874 | 534.89 | 881 | 867 | 173.9 |
| A | 0 | 226 | 7701 | 39.3 | 881 | 867 | 173.9 |
| B | 7 | 220 | 102870 | 631.6 | 867 | 849 | 161.5 |
| B | 3 | 64 | 49670 | 302.24 | 867 | 849 | 161.5 |
| B | 0 | 245 | 38568 | 233.51 | 867 | 849 | 161.5 |
| C | 14 | 238 | 132937 | 696.37 | 830 | 837 | 189.7 |
| C | 9 | 221 | 72414 | 377.32 | 830 | 837 | 189.7 |
| C | 3 | 233 | 67404 | 350.91 | 830 | 837 | 189.7 |
| D | 12 | 218 | 741654 | 3733.9 | 832 | 808 | 198.4 |
| D | 7 | 238 | 426822 | 2147.13 | 832 | 808 | 198.4 |
| D | 1 | 52 | 118419 | 592.76 | 832 | 808 | 198.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
