| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_180T01_9000002986_20045cztM0_level2.evt | modeM0/AS1A05_180T01_9000002986_20045cztM0_level2_quad_clean.evt |
| Size (bytes) | 508,121,280 | 83,122,560 |
| Size | 484.6 MB | 79.3 MB |
| Events in quadrant A | 3,494,742 | 535,904 |
| Events in quadrant B | 3,490,187 | 535,512 |
| Events in quadrant C | 3,411,432 | 505,371 |
| Events in quadrant D | 4,559,903 | 495,430 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14255 | 2 |
| B | 0 | 14202 | 2 |
| C | 0 | 13932 | 2 |
| D | 0 | 17765 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6372 | 70 | 1.098556% |
| B | 6373 | 71 | 1.114075% |
| C | 6373 | 89 | 1.396517% |
| D | 6373 | 195 | 3.059783% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7612 | 6373 | 11 | 11 | 0.14% | 0.17% |  |
| B | 7613 | 6374 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7613 | 6374 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7613 | 6374 | 126 | 126 | 1.66% | 1.98% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 238 | 62186 | 347.19 | 888 | 874 | 176.6 |
| A | 0 | 226 | 7785 | 39.13 | 888 | 874 | 176.6 |
| A | 3 | 1 | 7468 | 37.34 | 888 | 874 | 176.6 |
| B | 0 | 198 | 28248 | 167.18 | 873 | 856 | 163.8 |
| B | 4 | 80 | 21539 | 126.23 | 873 | 856 | 163.8 |
| B | 12 | 111 | 19017 | 110.84 | 873 | 856 | 163.8 |
| C | 14 | 238 | 135127 | 703.32 | 831 | 839 | 190.9 |
| C | 3 | 233 | 27003 | 137.03 | 831 | 839 | 190.9 |
| C | 7 | 220 | 9855 | 47.22 | 831 | 839 | 190.9 |
| D | 1 | 52 | 843204 | 4130.23 | 848 | 824 | 204.0 |
| D | 12 | 218 | 369001 | 1805.19 | 848 | 824 | 204.0 |
| D | 12 | 250 | 52028 | 251.06 | 848 | 824 | 204.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
