| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_117T01_9000002998_20220cztM0_level2.evt | modeM0/AS1A05_117T01_9000002998_20220cztM0_level2_quad_clean.evt |
| Size (bytes) | 467,449,920 | 97,058,880 |
| Size | 445.8 MB | 92.6 MB |
| Events in quadrant A | 3,285,962 | 644,800 |
| Events in quadrant B | 3,343,003 | 647,901 |
| Events in quadrant C | 3,299,067 | 612,136 |
| Events in quadrant D | 3,807,545 | 601,434 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13236 | 1 |
| B | 0 | 13435 | 1 |
| C | 0 | 13285 | 1 |
| D | 0 | 15085 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6206 | 34 | 0.547857% |
| B | 6206 | 40 | 0.644538% |
| C | 6206 | 50 | 0.805672% |
| D | 6205 | 59 | 0.950846% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7521 | 6207 | 5 | 5 | 0.07% | 0.08% |  |
| B | 7521 | 6207 | 5 | 5 | 0.07% | 0.08% |  |
| C | 7521 | 6207 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7520 | 6206 | 50 | 50 | 0.66% | 0.81% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 9 | 143 | 25337 | 146.53 | 842 | 826 | 167.3 |
| A | 14 | 238 | 15991 | 90.66 | 842 | 826 | 167.3 |
| A | 0 | 226 | 7392 | 39.25 | 842 | 826 | 167.3 |
| B | 7 | 220 | 51933 | 333.38 | 825 | 809 | 153.4 |
| B | 12 | 111 | 17659 | 109.88 | 825 | 809 | 153.4 |
| B | 11 | 111 | 15951 | 98.74 | 825 | 809 | 153.4 |
| C | 14 | 238 | 126273 | 675.65 | 801 | 811 | 185.7 |
| C | 3 | 233 | 42600 | 225.05 | 801 | 811 | 185.7 |
| C | 13 | 61 | 5520 | 25.36 | 801 | 811 | 185.7 |
| D | 1 | 52 | 243969 | 1226.76 | 823 | 802 | 198.2 |
| D | 11 | 176 | 226553 | 1138.89 | 823 | 802 | 198.2 |
| D | 9 | 85 | 135890 | 681.51 | 823 | 802 | 198.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
