| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_174T01_9000003008_20331cztM0_level2.evt | modeM0/AS1A05_174T01_9000003008_20331cztM0_level2_quad_clean.evt |
| Size (bytes) | 481,746,240 | 86,431,680 |
| Size | 459.4 MB | 82.4 MB |
| Events in quadrant A | 3,515,537 | 540,916 |
| Events in quadrant B | 3,871,939 | 547,961 |
| Events in quadrant C | 3,333,596 | 525,832 |
| Events in quadrant D | 3,398,651 | 520,681 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15017 | 2 |
| B | 0 | 15920 | 2 |
| C | 0 | 14229 | 2 |
| D | 0 | 14760 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 142 | 0 |
| B | 0 | 142 | 0 |
| C | 0 | 142 | 0 |
| D | 0 | 142 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6918 | 113 | 1.633420% |
| B | 6919 | 316 | 4.567134% |
| C | 6919 | 98 | 1.416390% |
| D | 6919 | 86 | 1.242954% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8628 | 6919 | 23 | 23 | 0.27% | 0.33% |  |
| B | 8629 | 6920 | 159 | 159 | 1.84% | 2.30% |  |
| C | 8629 | 6920 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8629 | 6921 | 27 | 27 | 0.31% | 0.39% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 215427 | 1243.9 | 851 | 834 | 172.5 |
| A | 15 | 191 | 18412 | 101.89 | 851 | 834 | 172.5 |
| A | 13 | 254 | 10021 | 53.25 | 851 | 834 | 172.5 |
| B | 4 | 142 | 464236 | 2881.41 | 833 | 813 | 160.8 |
| B | 7 | 220 | 56115 | 343.85 | 833 | 813 | 160.8 |
| B | 0 | 197 | 23705 | 142.34 | 833 | 813 | 160.8 |
| C | 14 | 238 | 126733 | 653.17 | 820 | 825 | 192.8 |
| C | 13 | 61 | 5721 | 25.4 | 820 | 825 | 192.8 |
| C | 1 | 16 | 5013 | 21.72 | 820 | 825 | 192.8 |
| D | 9 | 1 | 66049 | 320.63 | 832 | 808 | 203.5 |
| D | 2 | 120 | 64869 | 314.83 | 832 | 808 | 203.5 |
| D | 1 | 52 | 40354 | 194.35 | 832 | 808 | 203.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
