| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_163T01_9000003010_20350cztM0_level2.evt | modeM0/AS1A05_163T01_9000003010_20350cztM0_level2_quad_clean.evt |
| Size (bytes) | 2,515,455,360 | 509,734,080 |
| Size | 2.3 GB | 486.1 MB |
| Events in quadrant A | 17,910,214 | 3,234,346 |
| Events in quadrant B | 18,482,701 | 3,286,436 |
| Events in quadrant C | 18,511,663 | 3,178,316 |
| Events in quadrant D | 18,715,247 | 3,137,163 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 770 | 0 |
| B | 0 | 770 | 0 |
| C | 0 | 770 | 0 |
| D | 0 | 770 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 78244 | 7 |
| B | 0 | 79316 | 7 |
| C | 0 | 79518 | 7 |
| D | 0 | 81948 | 7 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 68 | 0 |
| B | 0 | 68 | 0 |
| C | 0 | 68 | 0 |
| D | 0 | 68 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 37920 | 271 | 0.714662% |
| B | 37921 | 374 | 0.986261% |
| C | 37921 | 579 | 1.526858% |
| D | 37921 | 413 | 1.089106% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 44600 | 37926 | 1 | 1 | 0.00% | 0.00% |  |
| B | 44601 | 37927 | 14 | 14 | 0.03% | 0.04% |  |
| C | 44601 | 37927 | 45 | 45 | 0.10% | 0.12% |  |
| D | 44601 | 37927 | 213 | 213 | 0.48% | 0.56% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 43935 | 42.67 | 4638 | 4547 | 923.0 |
| A | 0 | 226 | 39504 | 37.87 | 4638 | 4547 | 923.0 |
| A | 3 | 137 | 38900 | 37.22 | 4638 | 4547 | 923.0 |
| B | 0 | 198 | 199987 | 226.04 | 4617 | 4498 | 864.8 |
| B | 12 | 111 | 109956 | 121.94 | 4617 | 4498 | 864.8 |
| B | 11 | 111 | 98410 | 108.59 | 4617 | 4498 | 864.8 |
| C | 14 | 238 | 696361 | 660.39 | 4483 | 4527 | 1047.6 |
| C | 3 | 9 | 300836 | 282.84 | 4483 | 4527 | 1047.6 |
| C | 3 | 233 | 31496 | 25.74 | 4483 | 4527 | 1047.6 |
| D | 7 | 238 | 787652 | 721.03 | 4529 | 4409 | 1086.3 |
| D | 1 | 52 | 468700 | 427.41 | 4529 | 4409 | 1086.3 |
| D | 2 | 16 | 250374 | 226.43 | 4529 | 4409 | 1086.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
