| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_198T01_9000003014_20388cztM0_level2.evt | modeM0/AS1A05_198T01_9000003014_20388cztM0_level2_quad_clean.evt |
| Size (bytes) | 555,177,600 | 85,939,200 |
| Size | 529.5 MB | 82.0 MB |
| Events in quadrant A | 3,831,862 | 526,040 |
| Events in quadrant B | 4,126,068 | 524,877 |
| Events in quadrant C | 3,823,003 | 505,084 |
| Events in quadrant D | 4,496,727 | 497,256 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 160 | 0 |
| B | 0 | 160 | 0 |
| C | 0 | 160 | 0 |
| D | 0 | 160 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16347 | 3 |
| B | 0 | 17197 | 2 |
| C | 0 | 16242 | 2 |
| D | 0 | 18371 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7904 | 100 | 1.265182% |
| B | 7904 | 160 | 2.024291% |
| C | 7904 | 127 | 1.606781% |
| D | 7904 | 220 | 2.783401% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9269 | 7906 | 1 | 1 | 0.01% | 0.01% |  |
| B | 9269 | 7905 | 26 | 26 | 0.28% | 0.33% |  |
| C | 9269 | 7905 | 0 | 0 | 0.00% | 0.00% |  |
| D | 9269 | 7906 | 127 | 127 | 1.37% | 1.61% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 18821 | 89.52 | 986 | 964 | 199.5 |
| A | 13 | 210 | 11122 | 50.92 | 986 | 964 | 199.5 |
| A | 0 | 226 | 8579 | 38.17 | 986 | 964 | 199.5 |
| B | 7 | 220 | 215480 | 1134.46 | 973 | 948 | 189.1 |
| B | 0 | 198 | 23732 | 120.48 | 973 | 948 | 189.1 |
| B | 12 | 111 | 22830 | 115.71 | 973 | 948 | 189.1 |
| C | 14 | 238 | 145805 | 657.25 | 938 | 944 | 220.4 |
| C | 0 | 207 | 8770 | 35.51 | 938 | 944 | 220.4 |
| C | 10 | 91 | 8500 | 34.28 | 938 | 944 | 220.4 |
| D | 1 | 52 | 767754 | 3287.95 | 953 | 926 | 233.2 |
| D | 1 | 20 | 49627 | 208.82 | 953 | 926 | 233.2 |
| D | 2 | 234 | 28252 | 117.17 | 953 | 926 | 233.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
