| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_198T01_9000003014_20399cztM0_level2.evt | modeM0/AS1A05_198T01_9000003014_20399cztM0_level2_quad_clean.evt |
| Size (bytes) | 585,584,640 | 99,069,120 |
| Size | 558.5 MB | 94.5 MB |
| Events in quadrant A | 3,673,912 | 632,190 |
| Events in quadrant B | 3,879,285 | 639,810 |
| Events in quadrant C | 3,716,287 | 614,400 |
| Events in quadrant D | 5,940,916 | 576,376 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 156 | 0 |
| B | 0 | 156 | 0 |
| C | 0 | 156 | 0 |
| D | 0 | 156 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15939 | 1 |
| B | 0 | 16385 | 1 |
| C | 0 | 15941 | 1 |
| D | 0 | 22708 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1 | 0 |
| B | 0 | 1 | 0 |
| C | 0 | 1 | 0 |
| D | 0 | 1 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7721 | 250 | 3.237923% |
| B | 7722 | 283 | 3.664854% |
| C | 7722 | 247 | 3.198653% |
| D | 7722 | 998 | 12.924113% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7776 | 7722 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7777 | 7723 | 11 | 11 | 0.14% | 0.14% |  |
| C | 7777 | 7723 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7777 | 7723 | 726 | 726 | 9.34% | 9.40% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 96 | 8681 | 40.29 | 951 | 927 | 192.5 |
| A | 3 | 137 | 8127 | 37.41 | 951 | 927 | 192.5 |
| A | 0 | 226 | 8106 | 37.3 | 951 | 927 | 192.5 |
| B | 0 | 189 | 97600 | 529.55 | 938 | 911 | 182.6 |
| B | 3 | 64 | 42625 | 228.46 | 938 | 911 | 182.6 |
| B | 12 | 111 | 22512 | 118.3 | 938 | 911 | 182.6 |
| C | 14 | 238 | 141160 | 653.26 | 912 | 917 | 214.7 |
| C | 13 | 61 | 6397 | 25.53 | 912 | 917 | 214.7 |
| C | 3 | 233 | 5853 | 22.99 | 912 | 917 | 214.7 |
| D | 1 | 52 | 2521600 | 11611.95 | 884 | 858 | 217.1 |
| D | 2 | 184 | 42859 | 193.48 | 884 | 858 | 217.1 |
| D | 2 | 234 | 30602 | 137.02 | 884 | 858 | 217.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
