| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_198T01_9000003014_20400cztM0_level2.evt | modeM0/AS1A05_198T01_9000003014_20400cztM0_level2_quad_clean.evt |
| Size (bytes) | 511,934,400 | 89,038,080 |
| Size | 488.2 MB | 84.9 MB |
| Events in quadrant A | 3,577,561 | 555,896 |
| Events in quadrant B | 3,909,309 | 559,136 |
| Events in quadrant C | 3,579,217 | 537,801 |
| Events in quadrant D | 3,928,897 | 521,835 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 152 | 0 |
| B | 0 | 152 | 0 |
| C | 0 | 152 | 0 |
| D | 0 | 152 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15463 | 1 |
| B | 0 | 16232 | 1 |
| C | 0 | 15392 | 2 |
| D | 0 | 16814 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7491 | 146 | 1.949005% |
| B | 7491 | 191 | 2.549726% |
| C | 7491 | 150 | 2.002403% |
| D | 7491 | 250 | 3.337338% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7751 | 7492 | 3 | 3 | 0.04% | 0.04% |  |
| B | 7751 | 7492 | 20 | 20 | 0.26% | 0.27% |  |
| C | 7751 | 7492 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7751 | 7492 | 127 | 127 | 1.64% | 1.70% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 27197 | 141.37 | 918 | 899 | 186.0 |
| A | 12 | 96 | 11654 | 57.82 | 918 | 899 | 186.0 |
| A | 3 | 137 | 7860 | 37.42 | 918 | 899 | 186.0 |
| B | 7 | 220 | 171411 | 964.5 | 906 | 880 | 176.8 |
| B | 0 | 189 | 100155 | 561.49 | 906 | 880 | 176.8 |
| B | 3 | 64 | 23535 | 128.13 | 906 | 880 | 176.8 |
| C | 14 | 238 | 135134 | 646.07 | 878 | 883 | 207.8 |
| C | 8 | 128 | 10544 | 46.49 | 878 | 883 | 207.8 |
| C | 13 | 61 | 6205 | 25.61 | 878 | 883 | 207.8 |
| D | 1 | 52 | 525056 | 2407.87 | 890 | 863 | 217.7 |
| D | 2 | 234 | 31419 | 140.36 | 890 | 863 | 217.7 |
| D | 7 | 238 | 18871 | 82.72 | 890 | 863 | 217.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
