| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_198T01_9000003024_20464cztM0_level2.evt | modeM0/AS1A05_198T01_9000003024_20464cztM0_level2_quad_clean.evt |
| Size (bytes) | 480,646,080 | 84,614,400 |
| Size | 458.4 MB | 80.7 MB |
| Events in quadrant A | 3,383,539 | 539,403 |
| Events in quadrant B | 3,617,683 | 540,071 |
| Events in quadrant C | 3,625,258 | 513,756 |
| Events in quadrant D | 3,482,911 | 510,059 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22 | 0 |
| B | 0 | 22 | 0 |
| C | 0 | 22 | 0 |
| D | 0 | 22 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14312 | 2 |
| B | 0 | 15152 | 2 |
| C | 0 | 15071 | 2 |
| D | 0 | 14817 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6580 | 75 | 1.139818% |
| B | 6581 | 123 | 1.869017% |
| C | 6581 | 144 | 2.188117% |
| D | 6581 | 83 | 1.261207% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8770 | 6580 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8771 | 6581 | 13 | 13 | 0.15% | 0.20% |  |
| C | 8771 | 6581 | 9 | 9 | 0.10% | 0.14% |  |
| D | 8771 | 6581 | 16 | 16 | 0.18% | 0.24% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 222 | 29487 | 165.34 | 871 | 853 | 173.2 |
| A | 13 | 254 | 8219 | 42.53 | 871 | 853 | 173.2 |
| A | 0 | 226 | 7709 | 39.59 | 871 | 853 | 173.2 |
| B | 0 | 189 | 74783 | 450.13 | 865 | 845 | 164.3 |
| B | 7 | 220 | 44041 | 262.97 | 865 | 845 | 164.3 |
| B | 0 | 197 | 35836 | 213.02 | 865 | 845 | 164.3 |
| C | 3 | 9 | 156066 | 804.41 | 833 | 840 | 193.0 |
| C | 14 | 238 | 132015 | 679.78 | 833 | 840 | 193.0 |
| C | 3 | 233 | 64453 | 329.66 | 833 | 840 | 193.0 |
| D | 15 | 0 | 76432 | 369.42 | 848 | 825 | 204.7 |
| D | 1 | 52 | 70874 | 342.27 | 848 | 825 | 204.7 |
| D | 7 | 96 | 40551 | 194.1 | 848 | 825 | 204.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
