| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_208T03_9000003026_20477cztM0_level2.evt | modeM0/AS1A05_208T03_9000003026_20477cztM0_level2_quad_clean.evt |
| Size (bytes) | 474,094,080 | 83,473,920 |
| Size | 452.1 MB | 79.6 MB |
| Events in quadrant A | 3,275,847 | 539,976 |
| Events in quadrant B | 3,291,415 | 545,622 |
| Events in quadrant C | 2,876,124 | 525,939 |
| Events in quadrant D | 4,508,125 | 497,871 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13690 | 1 |
| B | 0 | 13828 | 1 |
| C | 0 | 12456 | 1 |
| D | 0 | 17480 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5988 | 90 | 1.503006% |
| B | 5988 | 61 | 1.018704% |
| C | 5988 | 54 | 0.901804% |
| D | 5988 | 337 | 5.627923% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7093 | 5988 | 71 | 71 | 1.00% | 1.19% |  |
| B | 7093 | 5988 | 17 | 17 | 0.24% | 0.28% |  |
| C | 7093 | 5988 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7093 | 5988 | 310 | 310 | 4.37% | 5.18% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 357448 | 2465.43 | 716 | 701 | 144.7 |
| A | 9 | 143 | 145992 | 1004.09 | 716 | 701 | 144.7 |
| A | 13 | 254 | 8772 | 55.78 | 716 | 701 | 144.7 |
| B | 0 | 189 | 216066 | 1574.74 | 720 | 704 | 136.8 |
| B | 0 | 197 | 56761 | 409.89 | 720 | 704 | 136.8 |
| B | 0 | 190 | 47897 | 345.08 | 720 | 704 | 136.8 |
| C | 14 | 238 | 107873 | 663.65 | 695 | 699 | 161.5 |
| C | 0 | 207 | 20896 | 125.06 | 695 | 699 | 161.5 |
| C | 3 | 9 | 14727 | 86.86 | 695 | 699 | 161.5 |
| D | 1 | 52 | 473621 | 2827.59 | 693 | 674 | 167.3 |
| D | 7 | 238 | 352959 | 2106.19 | 693 | 674 | 167.3 |
| D | 5 | 222 | 331710 | 1979.15 | 693 | 674 | 167.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
