| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_115T01_9000003030_20493cztM0_level2.evt | modeM0/AS1A05_115T01_9000003030_20493cztM0_level2_quad_clean.evt |
| Size (bytes) | 500,863,680 | 75,821,760 |
| Size | 477.7 MB | 72.3 MB |
| Events in quadrant A | 2,752,782 | 496,205 |
| Events in quadrant B | 3,261,355 | 498,081 |
| Events in quadrant C | 2,877,749 | 476,747 |
| Events in quadrant D | 5,890,957 | 426,737 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 116 | 0 |
| B | 0 | 116 | 0 |
| C | 0 | 116 | 0 |
| D | 0 | 116 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12025 | 1 |
| B | 0 | 13369 | 1 |
| C | 0 | 12185 | 2 |
| D | 0 | 21487 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5689 | 41 | 0.720689% |
| B | 5689 | 93 | 1.634734% |
| C | 5688 | 56 | 0.984529% |
| D | 5688 | 735 | 12.921941% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6844 | 5689 | 7 | 7 | 0.10% | 0.12% |  |
| B | 6844 | 5689 | 24 | 24 | 0.35% | 0.42% |  |
| C | 6843 | 5688 | 0 | 0 | 0.00% | 0.00% |  |
| D | 6843 | 5688 | 785 | 785 | 11.47% | 13.80% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 44768 | 316.04 | 693 | 678 | 139.5 |
| A | 12 | 96 | 42602 | 300.52 | 693 | 678 | 139.5 |
| A | 0 | 226 | 6156 | 39.27 | 693 | 678 | 139.5 |
| B | 0 | 197 | 259414 | 1960.91 | 692 | 675 | 131.9 |
| B | 0 | 189 | 147856 | 1115.45 | 692 | 675 | 131.9 |
| B | 0 | 219 | 62819 | 470.97 | 692 | 675 | 131.9 |
| C | 3 | 233 | 137166 | 880.87 | 668 | 674 | 155.0 |
| C | 14 | 238 | 105448 | 676.17 | 668 | 674 | 155.0 |
| C | 3 | 247 | 18598 | 115.67 | 668 | 674 | 155.0 |
| D | 7 | 38 | 1667130 | 10320.03 | 657 | 636 | 161.5 |
| D | 7 | 238 | 531469 | 3287.27 | 657 | 636 | 161.5 |
| D | 2 | 165 | 230499 | 1423.46 | 657 | 636 | 161.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
