| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_115T01_9000003030_20510cztM0_level2.evt | modeM0/AS1A05_115T01_9000003030_20510cztM0_level2_quad_clean.evt |
| Size (bytes) | 587,364,480 | 88,876,800 |
| Size | 560.2 MB | 84.8 MB |
| Events in quadrant A | 3,213,497 | 614,429 |
| Events in quadrant B | 3,379,675 | 631,329 |
| Events in quadrant C | 3,098,332 | 590,778 |
| Events in quadrant D | 7,687,179 | 432,052 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13287 | 2 |
| B | 0 | 13783 | 2 |
| C | 0 | 12854 | 2 |
| D | 0 | 26985 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6044 | 44 | 0.727995% |
| B | 6044 | 58 | 0.959629% |
| C | 6045 | 40 | 0.661704% |
| D | 6045 | 1557 | 25.756824% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7440 | 6044 | 15 | 15 | 0.20% | 0.25% |  |
| B | 7440 | 6045 | 8 | 8 | 0.11% | 0.13% |  |
| C | 7441 | 6046 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7441 | 6045 | 1534 | 1534 | 20.62% | 25.38% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 107811 | 687.67 | 787 | 772 | 155.7 |
| A | 12 | 96 | 73290 | 465.89 | 787 | 772 | 155.7 |
| A | 0 | 226 | 6883 | 39.26 | 787 | 772 | 155.7 |
| B | 0 | 189 | 63152 | 424.63 | 797 | 781 | 146.9 |
| B | 10 | 246 | 52770 | 353.95 | 797 | 781 | 146.9 |
| B | 0 | 219 | 48678 | 326.09 | 797 | 781 | 146.9 |
| C | 14 | 238 | 120528 | 677.12 | 759 | 766 | 176.9 |
| C | 7 | 220 | 7886 | 40.26 | 759 | 766 | 176.9 |
| C | 3 | 233 | 6208 | 30.77 | 759 | 766 | 176.9 |
| D | 2 | 16 | 3747966 | 23896.77 | 642 | 622 | 156.8 |
| D | 7 | 38 | 503533 | 3207.06 | 642 | 622 | 156.8 |
| D | 1 | 52 | 400419 | 2549.5 | 642 | 622 | 156.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
