| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_115T03_9000003032_20528cztM0_level2.evt | modeM0/AS1A05_115T03_9000003032_20528cztM0_level2_quad_clean.evt |
| Size (bytes) | 700,315,200 | 77,224,320 |
| Size | 667.9 MB | 73.6 MB |
| Events in quadrant A | 4,322,228 | 483,098 |
| Events in quadrant B | 3,918,062 | 505,117 |
| Events in quadrant C | 3,435,070 | 485,425 |
| Events in quadrant D | 9,051,552 | 367,836 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17521 | 2 |
| B | 0 | 16212 | 2 |
| C | 0 | 14774 | 2 |
| D | 0 | 31771 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 144 | 0 |
| B | 0 | 144 | 0 |
| C | 0 | 144 | 0 |
| D | 0 | 144 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7124 | 406 | 5.699045% |
| B | 7124 | 249 | 3.495227% |
| C | 7123 | 152 | 2.133932% |
| D | 7123 | 1975 | 27.727081% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7718 | 7123 | 175 | 175 | 2.27% | 2.46% |  |
| B | 7718 | 7124 | 41 | 41 | 0.53% | 0.58% |  |
| C | 7717 | 7122 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7717 | 7122 | 1938 | 1938 | 25.11% | 27.21% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 254 | 958570 | 5533.47 | 854 | 836 | 173.1 |
| A | 2 | 79 | 60052 | 342.13 | 854 | 836 | 173.1 |
| A | 11 | 29 | 10793 | 57.53 | 854 | 836 | 173.1 |
| B | 7 | 220 | 300032 | 1769.21 | 878 | 854 | 169.1 |
| B | 0 | 197 | 71466 | 417.57 | 878 | 854 | 169.1 |
| B | 0 | 189 | 57421 | 334.51 | 878 | 854 | 169.1 |
| C | 14 | 238 | 129866 | 651.43 | 843 | 848 | 198.1 |
| C | 3 | 9 | 12894 | 60.82 | 843 | 848 | 198.1 |
| C | 13 | 61 | 5991 | 25.97 | 843 | 848 | 198.1 |
| D | 12 | 238 | 3805627 | 20906.22 | 732 | 710 | 182.0 |
| D | 1 | 52 | 2078859 | 11418.44 | 732 | 710 | 182.0 |
| D | 7 | 238 | 109951 | 600.23 | 732 | 710 | 182.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
