| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_003T04_9000003046_20587cztM0_level2.evt | modeM0/AS1A06_003T04_9000003046_20587cztM0_level2_quad_clean.evt |
| Size (bytes) | 520,110,720 | 101,865,600 |
| Size | 496.0 MB | 97.1 MB |
| Events in quadrant A | 3,430,115 | 652,165 |
| Events in quadrant B | 4,160,691 | 656,091 |
| Events in quadrant C | 3,553,146 | 638,911 |
| Events in quadrant D | 4,109,780 | 627,539 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15141 | 2 |
| B | 0 | 17451 | 2 |
| C | 0 | 15311 | 2 |
| D | 0 | 17304 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 150 | 0 |
| B | 0 | 150 | 0 |
| C | 0 | 150 | 0 |
| D | 0 | 150 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7327 | 23 | 0.313907% |
| B | 7327 | 197 | 2.688686% |
| C | 7327 | 70 | 0.955371% |
| D | 7327 | 143 | 1.951686% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7757 | 7328 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7757 | 7328 | 69 | 69 | 0.89% | 0.94% |  |
| C | 7757 | 7328 | 1 | 1 | 0.01% | 0.01% |  |
| D | 7757 | 7328 | 70 | 70 | 0.90% | 0.96% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 16 | 11764 | 60.79 | 886 | 867 | 179.3 |
| A | 8 | 205 | 9723 | 49.4 | 886 | 867 | 179.3 |
| A | 12 | 194 | 8414 | 42.1 | 886 | 867 | 179.3 |
| B | 7 | 220 | 384833 | 2272.32 | 883 | 863 | 169.0 |
| B | 0 | 189 | 70075 | 409.59 | 883 | 863 | 169.0 |
| B | 5 | 172 | 40022 | 231.74 | 883 | 863 | 169.0 |
| C | 14 | 238 | 132363 | 653.31 | 856 | 862 | 201.3 |
| C | 8 | 208 | 69431 | 340.66 | 856 | 862 | 201.3 |
| C | 5 | 112 | 14596 | 68.23 | 856 | 862 | 201.3 |
| D | 5 | 222 | 282553 | 1229.7 | 850 | 834 | 229.1 |
| D | 13 | 153 | 162676 | 706.44 | 850 | 834 | 229.1 |
| D | 1 | 20 | 103760 | 449.27 | 850 | 834 | 229.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
