| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_003T04_9000003046_20592cztM0_level2.evt | modeM0/AS1A06_003T04_9000003046_20592cztM0_level2_quad_clean.evt |
| Size (bytes) | 544,193,280 | 86,906,880 |
| Size | 519.0 MB | 82.9 MB |
| Events in quadrant A | 3,091,145 | 554,841 |
| Events in quadrant B | 3,525,623 | 565,371 |
| Events in quadrant C | 3,313,275 | 540,954 |
| Events in quadrant D | 6,109,815 | 516,628 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13251 | 1 |
| B | 0 | 14487 | 1 |
| C | 0 | 13888 | 1 |
| D | 0 | 22648 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6507 | 34 | 0.522514% |
| B | 6508 | 102 | 1.567302% |
| C | 6508 | 69 | 1.060234% |
| D | 6508 | 563 | 8.650891% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7472 | 6508 | 2 | 2 | 0.03% | 0.03% |  |
| B | 7473 | 6509 | 48 | 48 | 0.64% | 0.74% |  |
| C | 7473 | 6509 | 4 | 4 | 0.05% | 0.06% |  |
| D | 7473 | 6509 | 421 | 421 | 5.63% | 6.47% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 16 | 23937 | 144.48 | 787 | 771 | 160.3 |
| A | 15 | 174 | 22582 | 136.03 | 787 | 771 | 160.3 |
| A | 12 | 194 | 9171 | 52.39 | 787 | 771 | 160.3 |
| B | 7 | 220 | 290109 | 1938.48 | 779 | 758 | 149.3 |
| B | 4 | 171 | 45656 | 300.79 | 779 | 758 | 149.3 |
| B | 0 | 190 | 33067 | 216.45 | 779 | 758 | 149.3 |
| C | 8 | 208 | 243695 | 1386.62 | 747 | 754 | 175.2 |
| C | 14 | 238 | 118402 | 671.49 | 747 | 754 | 175.2 |
| C | 9 | 54 | 35971 | 201.01 | 747 | 754 | 175.2 |
| D | 5 | 222 | 2697550 | 14798.32 | 743 | 720 | 182.2 |
| D | 2 | 165 | 266276 | 1457.19 | 743 | 720 | 182.2 |
| D | 1 | 20 | 165988 | 906.88 | 743 | 720 | 182.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
