| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_003T04_9000003046_20595cztM0_level2.evt | modeM0/AS1A06_003T04_9000003046_20595cztM0_level2_quad_clean.evt |
| Size (bytes) | 595,039,680 | 74,612,160 |
| Size | 567.5 MB | 71.2 MB |
| Events in quadrant A | 3,397,533 | 466,938 |
| Events in quadrant B | 4,030,727 | 470,369 |
| Events in quadrant C | 3,658,723 | 447,847 |
| Events in quadrant D | 6,493,359 | 420,200 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14064 | 1 |
| B | 0 | 16246 | 1 |
| C | 0 | 14830 | 1 |
| D | 0 | 23850 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6504 | 74 | 1.137761% |
| B | 6505 | 136 | 2.090699% |
| C | 6505 | 93 | 1.429669% |
| D | 6505 | 973 | 14.957725% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7694 | 6505 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7695 | 6506 | 26 | 26 | 0.34% | 0.40% |  |
| C | 7695 | 6506 | 7 | 7 | 0.09% | 0.11% |  |
| D | 7695 | 6506 | 779 | 779 | 10.12% | 11.97% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 239 | 28441 | 158.72 | 873 | 858 | 173.8 |
| A | 12 | 16 | 9766 | 51.26 | 873 | 858 | 173.8 |
| A | 0 | 226 | 7778 | 39.82 | 873 | 858 | 173.8 |
| B | 7 | 220 | 278387 | 1716.78 | 857 | 839 | 161.7 |
| B | 0 | 197 | 119045 | 731.17 | 857 | 839 | 161.7 |
| B | 0 | 189 | 95539 | 585.77 | 857 | 839 | 161.7 |
| C | 8 | 208 | 161364 | 844.13 | 823 | 831 | 190.2 |
| C | 9 | 54 | 140724 | 735.59 | 823 | 831 | 190.2 |
| C | 14 | 238 | 130792 | 683.37 | 823 | 831 | 190.2 |
| D | 5 | 222 | 1924978 | 10077.33 | 792 | 771 | 190.9 |
| D | 1 | 20 | 1340497 | 7016.33 | 792 | 771 | 190.9 |
| D | 13 | 153 | 86919 | 451.17 | 792 | 771 | 190.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
