| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_005T02_9000003048_20624cztM0_level2.evt | modeM0/AS1A06_005T02_9000003048_20624cztM0_level2_quad_clean.evt |
| Size (bytes) | 577,831,680 | 111,844,800 |
| Size | 551.1 MB | 106.7 MB |
| Events in quadrant A | 3,532,734 | 775,050 |
| Events in quadrant B | 3,571,412 | 771,622 |
| Events in quadrant C | 3,489,937 | 731,548 |
| Events in quadrant D | 6,468,581 | 658,847 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14755 | 2 |
| B | 0 | 14866 | 2 |
| C | 0 | 14690 | 2 |
| D | 0 | 23711 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6447 | 85 | 1.318443% |
| B | 6447 | 91 | 1.411509% |
| C | 6447 | 121 | 1.876842% |
| D | 6447 | 967 | 14.999224% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7622 | 6447 | 5 | 5 | 0.07% | 0.08% |  |
| B | 7622 | 6448 | 6 | 6 | 0.08% | 0.09% |  |
| C | 7622 | 6448 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7622 | 6448 | 805 | 805 | 10.56% | 12.48% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 122183 | 698.15 | 872 | 857 | 173.8 |
| A | 15 | 174 | 49625 | 280.63 | 872 | 857 | 173.8 |
| A | 12 | 16 | 8736 | 45.34 | 872 | 857 | 173.8 |
| B | 7 | 220 | 85253 | 527.97 | 856 | 838 | 159.9 |
| B | 0 | 190 | 28373 | 172.22 | 856 | 838 | 159.9 |
| B | 0 | 197 | 28285 | 171.67 | 856 | 838 | 159.9 |
| C | 8 | 208 | 156762 | 827.79 | 818 | 827 | 188.4 |
| C | 14 | 238 | 129947 | 685.44 | 818 | 827 | 188.4 |
| C | 3 | 233 | 11236 | 55.26 | 818 | 827 | 188.4 |
| D | 1 | 20 | 2603887 | 13272.24 | 802 | 778 | 196.1 |
| D | 5 | 222 | 265898 | 1351.74 | 802 | 778 | 196.1 |
| D | 2 | 165 | 197146 | 1001.2 | 802 | 778 | 196.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
