| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_005T02_9000003048_20625cztM0_level2.evt | modeM0/AS1A06_005T02_9000003048_20625cztM0_level2_quad_clean.evt |
| Size (bytes) | 477,924,480 | 112,812,480 |
| Size | 455.8 MB | 107.6 MB |
| Events in quadrant A | 3,200,390 | 780,607 |
| Events in quadrant B | 3,427,029 | 767,927 |
| Events in quadrant C | 3,624,012 | 723,958 |
| Events in quadrant D | 3,811,175 | 720,873 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13391 | 1 |
| B | 0 | 14159 | 1 |
| C | 0 | 14691 | 1 |
| D | 0 | 15370 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6067 | 94 | 1.549365% |
| B | 6067 | 107 | 1.763639% |
| C | 6068 | 122 | 2.010547% |
| D | 6068 | 139 | 2.290705% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7322 | 6068 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7322 | 6068 | 14 | 14 | 0.19% | 0.23% |  |
| C | 7323 | 6069 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7323 | 6069 | 63 | 63 | 0.86% | 1.04% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 37466 | 223.36 | 821 | 807 | 164.1 |
| A | 0 | 226 | 7236 | 39.17 | 821 | 807 | 164.1 |
| A | 15 | 174 | 6902 | 37.14 | 821 | 807 | 164.1 |
| B | 7 | 220 | 125051 | 823.88 | 800 | 783 | 150.8 |
| B | 0 | 197 | 36116 | 234.25 | 800 | 783 | 150.8 |
| B | 0 | 190 | 34114 | 220.98 | 800 | 783 | 150.8 |
| C | 3 | 233 | 351168 | 2011.07 | 759 | 766 | 174.2 |
| C | 8 | 208 | 171280 | 978.63 | 759 | 766 | 174.2 |
| C | 14 | 238 | 120489 | 687.13 | 759 | 766 | 174.2 |
| D | 1 | 52 | 442638 | 2326.92 | 784 | 763 | 189.9 |
| D | 13 | 153 | 118412 | 619.54 | 784 | 763 | 189.9 |
| D | 1 | 20 | 98400 | 514.16 | 784 | 763 | 189.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
