| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_005T02_9000003048_20628cztM0_level2.evt | modeM0/AS1A06_005T02_9000003048_20628cztM0_level2_quad_clean.evt |
| Size (bytes) | 573,854,400 | 89,928,000 |
| Size | 547.3 MB | 85.8 MB |
| Events in quadrant A | 3,113,154 | 612,328 |
| Events in quadrant B | 3,265,588 | 605,840 |
| Events in quadrant C | 3,233,820 | 574,047 |
| Events in quadrant D | 7,339,921 | 491,103 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13362 | 1 |
| B | 0 | 13688 | 1 |
| C | 0 | 13746 | 1 |
| D | 0 | 26104 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6296 | 36 | 0.571792% |
| B | 6297 | 65 | 1.032238% |
| C | 6297 | 92 | 1.461013% |
| D | 6297 | 1151 | 18.278545% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7416 | 6297 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7417 | 6298 | 20 | 20 | 0.27% | 0.32% |  |
| C | 7417 | 6298 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7417 | 6298 | 970 | 970 | 13.08% | 15.40% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 16 | 45238 | 280.76 | 792 | 777 | 158.4 |
| A | 12 | 194 | 14985 | 89.72 | 792 | 777 | 158.4 |
| A | 5 | 16 | 14615 | 87.38 | 792 | 777 | 158.4 |
| B | 0 | 244 | 71645 | 474.06 | 783 | 764 | 149.5 |
| B | 0 | 190 | 40181 | 263.62 | 783 | 764 | 149.5 |
| B | 0 | 219 | 20317 | 130.77 | 783 | 764 | 149.5 |
| C | 8 | 208 | 216793 | 1258.43 | 740 | 746 | 171.7 |
| C | 14 | 238 | 117025 | 677.3 | 740 | 746 | 171.7 |
| C | 3 | 233 | 6893 | 35.8 | 740 | 746 | 171.7 |
| D | 1 | 52 | 2771148 | 16221.56 | 703 | 683 | 170.8 |
| D | 5 | 222 | 1252276 | 7328.3 | 703 | 683 | 170.8 |
| D | 1 | 20 | 307145 | 1794.39 | 703 | 683 | 170.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
