| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_103T06_9000003056_20657cztM0_level2.evt | modeM0/AS1A05_103T06_9000003056_20657cztM0_level2_quad_clean.evt |
| Size (bytes) | 483,321,600 | 100,736,640 |
| Size | 460.9 MB | 96.1 MB |
| Events in quadrant A | 3,276,022 | 667,983 |
| Events in quadrant B | 3,414,672 | 667,962 |
| Events in quadrant C | 3,245,601 | 633,223 |
| Events in quadrant D | 4,251,784 | 620,402 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13970 | 2 |
| B | 0 | 14290 | 2 |
| C | 0 | 13911 | 2 |
| D | 0 | 17107 | 3 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6619 | 93 | 1.405046% |
| B | 6619 | 88 | 1.329506% |
| C | 6619 | 117 | 1.767639% |
| D | 6618 | 119 | 1.798126% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7699 | 6620 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7699 | 6620 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7699 | 6620 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7698 | 6619 | 85 | 85 | 1.10% | 1.28% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 252 | 16093 | 90.02 | 843 | 827 | 169.6 |
| A | 13 | 210 | 11995 | 65.85 | 843 | 827 | 169.6 |
| A | 5 | 16 | 9264 | 49.75 | 843 | 827 | 169.6 |
| B | 0 | 197 | 33856 | 207.21 | 836 | 816 | 159.5 |
| B | 0 | 244 | 30908 | 188.72 | 836 | 816 | 159.5 |
| B | 12 | 111 | 18113 | 108.48 | 836 | 816 | 159.5 |
| C | 14 | 238 | 124273 | 672.16 | 789 | 794 | 183.7 |
| C | 7 | 247 | 31747 | 168.49 | 789 | 794 | 183.7 |
| C | 8 | 208 | 6672 | 32.0 | 789 | 794 | 183.7 |
| D | 1 | 239 | 743348 | 3765.01 | 806 | 781 | 197.2 |
| D | 1 | 52 | 172055 | 868.4 | 806 | 781 | 197.2 |
| D | 1 | 20 | 111025 | 558.97 | 806 | 781 | 197.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
