| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_165T07_9000003062_20729cztM0_level2.evt | modeM0/AS1A05_165T07_9000003062_20729cztM0_level2_quad_clean.evt |
| Size (bytes) | 525,058,560 | 81,794,880 |
| Size | 500.7 MB | 78.0 MB |
| Events in quadrant A | 2,921,530 | 552,621 |
| Events in quadrant B | 3,322,101 | 532,338 |
| Events in quadrant C | 2,813,152 | 515,438 |
| Events in quadrant D | 6,452,899 | 472,218 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 118 | 0 |
| B | 0 | 118 | 0 |
| C | 0 | 118 | 0 |
| D | 0 | 118 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12277 | 1 |
| B | 0 | 13601 | 1 |
| C | 0 | 12048 | 2 |
| D | 0 | 23367 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5779 | 55 | 0.951722% |
| B | 5779 | 121 | 2.093788% |
| C | 5778 | 67 | 1.159571% |
| D | 5779 | 863 | 14.933379% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6989 | 5780 | 12 | 12 | 0.17% | 0.21% |  |
| B | 6989 | 5780 | 47 | 47 | 0.67% | 0.81% |  |
| C | 6988 | 5779 | 0 | 0 | 0.00% | 0.00% |  |
| D | 6989 | 5780 | 770 | 770 | 11.02% | 13.32% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 6 | 240 | 78681 | 527.94 | 737 | 723 | 147.7 |
| A | 0 | 226 | 6571 | 39.6 | 737 | 723 | 147.7 |
| A | 3 | 137 | 5632 | 33.24 | 737 | 723 | 147.7 |
| B | 7 | 220 | 379162 | 2795.96 | 719 | 702 | 135.4 |
| B | 0 | 190 | 29205 | 210.57 | 719 | 702 | 135.4 |
| B | 0 | 197 | 26629 | 191.54 | 719 | 702 | 135.4 |
| C | 14 | 238 | 109555 | 687.43 | 685 | 690 | 158.4 |
| C | 3 | 233 | 21665 | 132.45 | 685 | 690 | 158.4 |
| C | 8 | 208 | 8183 | 47.31 | 685 | 690 | 158.4 |
| D | 1 | 20 | 2127038 | 13287.31 | 660 | 641 | 160.0 |
| D | 1 | 52 | 1203489 | 7516.29 | 660 | 641 | 160.0 |
| D | 7 | 38 | 378984 | 2364.17 | 660 | 641 | 160.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
