| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_013T01_9000003070_20755cztM0_level2.evt | modeM0/AS1A05_013T01_9000003070_20755cztM0_level2_quad_clean.evt |
| Size (bytes) | 488,658,240 | 118,267,200 |
| Size | 466.0 MB | 112.8 MB |
| Events in quadrant A | 3,404,991 | 808,045 |
| Events in quadrant B | 3,498,391 | 806,390 |
| Events in quadrant C | 3,416,901 | 773,536 |
| Events in quadrant D | 4,055,397 | 758,557 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14162 | 2 |
| B | 0 | 14438 | 2 |
| C | 0 | 14333 | 2 |
| D | 0 | 16279 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6237 | 63 | 1.010101% |
| B | 6237 | 79 | 1.266635% |
| C | 6237 | 126 | 2.020202% |
| D | 6237 | 114 | 1.827802% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7552 | 6237 | 2 | 2 | 0.03% | 0.03% |  |
| B | 7552 | 6237 | 7 | 7 | 0.09% | 0.11% |  |
| C | 7552 | 6237 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7552 | 6237 | 55 | 55 | 0.73% | 0.88% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 16568 | 89.49 | 882 | 866 | 175.5 |
| A | 0 | 226 | 7667 | 38.76 | 882 | 866 | 175.5 |
| A | 12 | 194 | 6310 | 31.03 | 882 | 866 | 175.5 |
| B | 7 | 220 | 102984 | 642.78 | 859 | 841 | 158.9 |
| B | 12 | 111 | 18044 | 108.26 | 859 | 841 | 158.9 |
| B | 0 | 189 | 17419 | 104.33 | 859 | 841 | 158.9 |
| C | 14 | 238 | 136551 | 718.51 | 834 | 843 | 188.9 |
| C | 3 | 233 | 27840 | 142.94 | 834 | 843 | 188.9 |
| C | 13 | 61 | 5679 | 25.6 | 834 | 843 | 188.9 |
| D | 1 | 20 | 396885 | 1920.43 | 858 | 834 | 206.2 |
| D | 1 | 52 | 356597 | 1725.07 | 858 | 834 | 206.2 |
| D | 5 | 222 | 40598 | 192.81 | 858 | 834 | 206.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
