| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_013T01_9000003070_20761cztM0_level2.evt | modeM0/AS1A05_013T01_9000003070_20761cztM0_level2_quad_clean.evt |
| Size (bytes) | 626,590,080 | 105,736,320 |
| Size | 597.6 MB | 100.8 MB |
| Events in quadrant A | 3,575,679 | 698,491 |
| Events in quadrant B | 3,595,994 | 695,789 |
| Events in quadrant C | 3,360,882 | 675,687 |
| Events in quadrant D | 7,951,497 | 625,814 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 146 | 0 |
| B | 0 | 148 | 0 |
| C | 0 | 148 | 0 |
| D | 0 | 148 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15439 | 3 |
| B | 0 | 15469 | 1 |
| C | 0 | 14880 | 5 |
| D | 0 | 28636 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7269 | 74 | 1.018022% |
| B | 7270 | 89 | 1.224209% |
| C | 7269 | 65 | 0.894208% |
| D | 7270 | 961 | 13.218707% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7495 | 7271 | 24 | 24 | 0.32% | 0.33% |  |
| B | 7495 | 7271 | 12 | 12 | 0.16% | 0.17% |  |
| C | 7495 | 7271 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7495 | 7271 | 770 | 770 | 10.27% | 10.59% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 224733 | 1266.32 | 871 | 853 | 176.8 |
| A | 0 | 226 | 7596 | 38.14 | 871 | 853 | 176.8 |
| A | 3 | 137 | 6987 | 34.7 | 871 | 853 | 176.8 |
| B | 7 | 220 | 100060 | 603.33 | 858 | 835 | 164.5 |
| B | 3 | 64 | 43945 | 262.13 | 858 | 835 | 164.5 |
| B | 0 | 230 | 31935 | 189.1 | 858 | 835 | 164.5 |
| C | 14 | 238 | 127942 | 658.3 | 821 | 827 | 193.1 |
| C | 7 | 220 | 17154 | 84.55 | 821 | 827 | 193.1 |
| C | 7 | 247 | 7917 | 36.72 | 821 | 827 | 193.1 |
| D | 1 | 20 | 1565881 | 7976.89 | 809 | 786 | 196.2 |
| D | 5 | 222 | 1455695 | 7415.3 | 809 | 786 | 196.2 |
| D | 12 | 227 | 961148 | 4894.72 | 809 | 786 | 196.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
