| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_013T01_9000003070_20827cztM0_level2.evt | modeM0/AS1A05_013T01_9000003070_20827cztM0_level2_quad_clean.evt |
| Size (bytes) | 741,637,440 | 81,780,480 |
| Size | 707.3 MB | 78.0 MB |
| Events in quadrant A | 3,020,019 | 594,589 |
| Events in quadrant B | 3,249,618 | 591,952 |
| Events in quadrant C | 3,093,838 | 580,001 |
| Events in quadrant D | 12,708,721 | 307,272 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 116 | 0 |
| B | 0 | 116 | 0 |
| C | 0 | 116 | 0 |
| D | 0 | 116 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12434 | 1 |
| B | 0 | 13176 | 1 |
| C | 0 | 12769 | 1 |
| D | 0 | 41693 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5743 | 40 | 0.696500% |
| B | 5743 | 67 | 1.166638% |
| C | 5743 | 92 | 1.601950% |
| D | 5743 | 4222 | 73.515584% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7028 | 5743 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7028 | 5743 | 7 | 7 | 0.10% | 0.12% |  |
| C | 7028 | 5743 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7027 | 5742 | 4206 | 4206 | 59.85% | 73.25% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 226 | 6871 | 38.83 | 786 | 775 | 157.0 |
| A | 3 | 137 | 5872 | 32.46 | 786 | 775 | 157.0 |
| A | 12 | 194 | 5595 | 30.7 | 786 | 775 | 157.0 |
| B | 7 | 220 | 62545 | 428.22 | 776 | 759 | 144.3 |
| B | 0 | 219 | 58172 | 397.91 | 776 | 759 | 144.3 |
| B | 0 | 189 | 58078 | 397.26 | 776 | 759 | 144.3 |
| C | 14 | 238 | 122650 | 705.47 | 759 | 768 | 172.8 |
| C | 9 | 54 | 10732 | 57.67 | 759 | 768 | 172.8 |
| C | 13 | 61 | 5377 | 26.68 | 759 | 768 | 172.8 |
| D | 1 | 52 | 10434660 | 87965.46 | 497 | 484 | 118.6 |
| D | 1 | 20 | 343844 | 2894.7 | 497 | 484 | 118.6 |
| D | 9 | 1 | 26751 | 221.44 | 497 | 484 | 118.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
