| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C04_001T01_9000003074_20848cztM0_level2.evt | modeM0/AS1C04_001T01_9000003074_20848cztM0_level2_quad_clean.evt |
| Size (bytes) | 718,205,760 | 108,826,560 |
| Size | 684.9 MB | 103.8 MB |
| Events in quadrant A | 3,159,561 | 764,869 |
| Events in quadrant B | 3,633,712 | 744,869 |
| Events in quadrant C | 3,227,802 | 723,391 |
| Events in quadrant D | 11,276,093 | 594,234 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14193 | 282 |
| B | 0 | 15777 | 647 |
| C | 0 | 14282 | 253 |
| D | 0 | 38806 | 691 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 4 |
| B | 0 | 138 | 2 |
| C | 0 | 138 | 4 |
| D | 0 | 138 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6720 | 62 | 0.922619% |
| B | 6695 | 146 | 2.180732% |
| C | 6740 | 110 | 1.632047% |
| D | 6673 | 2900 | 43.458714% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6994 | 6734 | 0 | 0 | 0.00% | 0.00% |  |
| B | 6986 | 6718 | 21 | 21 | 0.30% | 0.31% |  |
| C | 7000 | 6758 | 2 | 2 | 0.03% | 0.03% |  |
| D | 6978 | 6710 | 2752 | 2752 | 39.44% | 41.01% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 23137 | 136.58 | 807 | 790 | 163.6 |
| A | 2 | 79 | 22261 | 131.23 | 807 | 790 | 163.6 |
| A | 0 | 226 | 7097 | 38.55 | 807 | 790 | 163.6 |
| B | 7 | 220 | 199201 | 1311.16 | 793 | 772 | 151.3 |
| B | 0 | 189 | 165366 | 1087.59 | 793 | 772 | 151.3 |
| B | 0 | 190 | 58244 | 379.76 | 793 | 772 | 151.3 |
| C | 14 | 238 | 120058 | 658.11 | 773 | 777 | 181.2 |
| C | 9 | 54 | 23712 | 126.54 | 773 | 777 | 181.2 |
| C | 0 | 207 | 20297 | 107.7 | 773 | 777 | 181.2 |
| D | 1 | 20 | 7507989 | 44397.0 | 695 | 672 | 169.1 |
| D | 1 | 52 | 459650 | 2714.32 | 695 | 672 | 169.1 |
| D | 1 | 239 | 264761 | 1561.78 | 695 | 672 | 169.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
