| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_160T01_9000003078_20875cztM0_level2.evt | modeM0/AS1A05_160T01_9000003078_20875cztM0_level2_quad_clean.evt |
| Size (bytes) | 479,511,360 | 73,342,080 |
| Size | 457.3 MB | 69.9 MB |
| Events in quadrant A | 3,373,731 | 448,781 |
| Events in quadrant B | 3,564,111 | 456,016 |
| Events in quadrant C | 3,347,904 | 423,590 |
| Events in quadrant D | 3,778,541 | 422,617 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14029 | 2 |
| B | 0 | 14413 | 2 |
| C | 0 | 13961 | 2 |
| D | 0 | 15321 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6736 | 96 | 1.425178% |
| B | 6736 | 145 | 2.152613% |
| C | 6736 | 136 | 2.019002% |
| D | 6736 | 143 | 2.122922% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7556 | 6737 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7556 | 6737 | 32 | 32 | 0.42% | 0.47% |  |
| C | 7556 | 6737 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7556 | 6737 | 56 | 56 | 0.74% | 0.83% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 203 | 12516 | 66.35 | 874 | 857 | 175.7 |
| A | 0 | 226 | 7469 | 37.63 | 874 | 857 | 175.7 |
| A | 3 | 137 | 7330 | 36.84 | 874 | 857 | 175.7 |
| B | 15 | 201 | 72560 | 429.25 | 865 | 845 | 167.1 |
| B | 0 | 189 | 49916 | 293.72 | 865 | 845 | 167.1 |
| B | 0 | 229 | 31310 | 182.35 | 865 | 845 | 167.1 |
| C | 14 | 238 | 130158 | 671.02 | 823 | 830 | 192.7 |
| C | 9 | 54 | 10502 | 50.18 | 823 | 830 | 192.7 |
| C | 13 | 61 | 5694 | 25.24 | 823 | 830 | 192.7 |
| D | 1 | 239 | 280754 | 1377.6 | 842 | 819 | 203.2 |
| D | 1 | 20 | 156121 | 764.26 | 842 | 819 | 203.2 |
| D | 1 | 52 | 110874 | 541.6 | 842 | 819 | 203.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
