| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_002T03_9000003080_20886cztM0_level2.evt | modeM0/AS1A06_002T03_9000003080_20886cztM0_level2_quad_clean.evt |
| Size (bytes) | 515,525,760 | 68,955,840 |
| Size | 491.6 MB | 65.8 MB |
| Events in quadrant A | 3,274,868 | 419,910 |
| Events in quadrant B | 3,640,882 | 425,248 |
| Events in quadrant C | 3,392,595 | 416,789 |
| Events in quadrant D | 4,885,416 | 394,465 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13289 | 2 |
| B | 0 | 14605 | 3 |
| C | 0 | 13779 | 2 |
| D | 0 | 18333 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6171 | 44 | 0.713012% |
| B | 6171 | 90 | 1.458435% |
| C | 6171 | 106 | 1.717712% |
| D | 6171 | 491 | 7.956571% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7521 | 6172 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7521 | 6172 | 17 | 17 | 0.23% | 0.28% |  |
| C | 7521 | 6172 | 7 | 7 | 0.09% | 0.11% |  |
| D | 7521 | 6172 | 454 | 454 | 6.04% | 7.36% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 226 | 7129 | 37.3 | 851 | 836 | 168.7 |
| A | 3 | 137 | 6392 | 32.94 | 851 | 836 | 168.7 |
| A | 12 | 194 | 6042 | 30.86 | 851 | 836 | 168.7 |
| B | 7 | 220 | 132881 | 849.98 | 852 | 834 | 155.4 |
| B | 0 | 189 | 59198 | 375.69 | 852 | 834 | 155.4 |
| B | 0 | 230 | 39241 | 247.22 | 852 | 834 | 155.4 |
| C | 14 | 238 | 132943 | 696.11 | 829 | 836 | 189.8 |
| C | 9 | 54 | 23710 | 120.53 | 829 | 836 | 189.8 |
| C | 13 | 61 | 5710 | 25.68 | 829 | 836 | 189.8 |
| D | 13 | 174 | 1223436 | 6253.27 | 821 | 801 | 195.5 |
| D | 1 | 52 | 449317 | 2293.97 | 821 | 801 | 195.5 |
| D | 14 | 35 | 50378 | 253.57 | 821 | 801 | 195.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
