| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_002T03_9000003080_20899cztM0_level2.evt | modeM0/AS1A06_002T03_9000003080_20899cztM0_level2_quad_clean.evt |
| Size (bytes) | 380,226,240 | 61,597,440 |
| Size | 362.6 MB | 58.7 MB |
| Events in quadrant A | 2,652,101 | 372,589 |
| Events in quadrant B | 2,922,086 | 380,500 |
| Events in quadrant C | 2,705,993 | 371,623 |
| Events in quadrant D | 2,866,375 | 361,157 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11980 | 752 |
| B | 0 | 12765 | 776 |
| C | 0 | 12045 | 754 |
| D | 0 | 12724 | 779 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 116 | 6 |
| B | 0 | 115 | 9 |
| C | 0 | 116 | 8 |
| D | 0 | 116 | 6 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5423 | 30 | 0.553199% |
| B | 5418 | 40 | 0.738280% |
| C | 5422 | 43 | 0.793065% |
| D | 5425 | 73 | 1.345622% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6945 | 5481 | 3 | 3 | 0.04% | 0.05% |  |
| B | 6829 | 5481 | 4 | 4 | 0.06% | 0.07% |  |
| C | 6943 | 5488 | 0 | 0 | 0.00% | 0.00% |  |
| D | 6840 | 5483 | 57 | 57 | 0.83% | 1.04% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 22440 | 157.8 | 683 | 671 | 138.0 |
| A | 0 | 226 | 5956 | 38.31 | 683 | 671 | 138.0 |
| A | 3 | 137 | 5235 | 33.08 | 683 | 671 | 138.0 |
| B | 7 | 220 | 73642 | 568.47 | 687 | 671 | 128.4 |
| B | 0 | 230 | 54322 | 417.96 | 687 | 671 | 128.4 |
| B | 0 | 219 | 42580 | 326.49 | 687 | 671 | 128.4 |
| C | 14 | 238 | 106007 | 677.74 | 666 | 671 | 155.4 |
| C | 13 | 61 | 4581 | 25.16 | 666 | 671 | 155.4 |
| C | 7 | 247 | 1663 | 6.38 | 666 | 671 | 155.4 |
| D | 7 | 223 | 163820 | 1026.86 | 665 | 649 | 158.9 |
| D | 1 | 20 | 116840 | 731.21 | 665 | 649 | 158.9 |
| D | 1 | 52 | 57235 | 356.11 | 665 | 649 | 158.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
