| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_002T03_9000003080_20901cztM0_level2.evt | modeM0/AS1A06_002T03_9000003080_20901cztM0_level2_quad_clean.evt |
| Size (bytes) | 479,370,240 | 68,673,600 |
| Size | 457.2 MB | 65.5 MB |
| Events in quadrant A | 3,516,736 | 412,514 |
| Events in quadrant B | 3,675,802 | 419,182 |
| Events in quadrant C | 3,410,045 | 411,905 |
| Events in quadrant D | 3,493,214 | 401,512 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22 | 0 |
| B | 0 | 23 | 0 |
| C | 0 | 23 | 0 |
| D | 0 | 23 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14058 | 2 |
| B | 0 | 14724 | 2 |
| C | 0 | 13812 | 2 |
| D | 0 | 14025 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6223 | 35 | 0.562430% |
| B | 6223 | 80 | 1.285554% |
| C | 6222 | 89 | 1.430408% |
| D | 6222 | 40 | 0.642880% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7618 | 6224 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7618 | 6224 | 18 | 18 | 0.24% | 0.29% |  |
| C | 7617 | 6223 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7617 | 6223 | 21 | 21 | 0.28% | 0.34% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 6 | 16 | 218256 | 1291.55 | 856 | 843 | 168.3 |
| A | 0 | 226 | 7294 | 38.32 | 856 | 843 | 168.3 |
| A | 15 | 174 | 7242 | 38.01 | 856 | 843 | 168.3 |
| B | 7 | 220 | 118496 | 749.83 | 858 | 841 | 156.9 |
| B | 4 | 216 | 80296 | 506.38 | 858 | 841 | 156.9 |
| B | 0 | 230 | 47318 | 296.21 | 858 | 841 | 156.9 |
| C | 14 | 238 | 135897 | 708.19 | 839 | 848 | 190.7 |
| C | 13 | 61 | 5873 | 26.35 | 839 | 848 | 190.7 |
| C | 3 | 233 | 2863 | 10.57 | 839 | 848 | 190.7 |
| D | 7 | 38 | 147387 | 730.46 | 843 | 822 | 200.6 |
| D | 1 | 52 | 52293 | 256.52 | 843 | 822 | 200.6 |
| D | 1 | 239 | 49503 | 242.62 | 843 | 822 | 200.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
