| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_131T01_9000003090_20975cztM0_level2.evt | modeM0/AS1T03_131T01_9000003090_20975cztM0_level2_quad_clean.evt |
| Size (bytes) | 482,483,520 | 67,731,840 |
| Size | 460.1 MB | 64.6 MB |
| Events in quadrant A | 3,205,540 | 406,694 |
| Events in quadrant B | 3,529,083 | 410,460 |
| Events in quadrant C | 3,304,102 | 407,161 |
| Events in quadrant D | 4,141,962 | 383,078 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | -1 | -1 |
| D | 0 | -1 | -1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 19 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13206 | 2 |
| B | 0 | 14137 | 2 |
| C | 0 | 13370 | 2 |
| D | 0 | 16467 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6354 | 57 | 0.897073% |
| B | 6354 | 148 | 2.329241% |
| C | 6353 | 123 | 1.936093% |
| D | 6353 | 168 | 2.644420% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7584 | 6355 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7584 | 6355 | 40 | 40 | 0.53% | 0.63% |  |
| C | 7583 | 6354 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7583 | 6354 | 93 | 93 | 1.23% | 1.46% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 226 | 7263 | 38.44 | 834 | 818 | 167.7 |
| A | 3 | 137 | 6448 | 33.58 | 834 | 818 | 167.7 |
| A | 12 | 194 | 5822 | 29.84 | 834 | 818 | 167.7 |
| B | 7 | 220 | 203421 | 1309.7 | 834 | 816 | 154.7 |
| B | 12 | 111 | 18366 | 113.45 | 834 | 816 | 154.7 |
| B | 3 | 64 | 17867 | 110.22 | 834 | 816 | 154.7 |
| C | 14 | 238 | 128941 | 687.41 | 812 | 821 | 186.4 |
| C | 7 | 247 | 5770 | 26.55 | 812 | 821 | 186.4 |
| C | 13 | 61 | 5679 | 26.06 | 812 | 821 | 186.4 |
| D | 1 | 20 | 545693 | 2772.42 | 811 | 789 | 196.5 |
| D | 9 | 1 | 313634 | 1591.72 | 811 | 789 | 196.5 |
| D | 1 | 52 | 148254 | 750.29 | 811 | 789 | 196.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
