| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_104T05_9000003120_21118cztM0_level2.evt | modeM0/AS1A05_104T05_9000003120_21118cztM0_level2_quad_clean.evt |
| Size (bytes) | 550,399,680 | 90,270,720 |
| Size | 524.9 MB | 86.1 MB |
| Events in quadrant A | 3,285,352 | 597,947 |
| Events in quadrant B | 3,616,438 | 609,607 |
| Events in quadrant C | 3,185,748 | 569,023 |
| Events in quadrant D | 6,164,016 | 526,501 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22 | 0 |
| B | 0 | 23 | 0 |
| C | 0 | 23 | 0 |
| D | 0 | 23 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13504 | 1 |
| B | 0 | 14569 | 1 |
| C | 0 | 13091 | 1 |
| D | 0 | 22783 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6173 | 28 | 0.453588% |
| B | 6172 | 85 | 1.377187% |
| C | 6172 | 34 | 0.550875% |
| D | 6172 | 330 | 5.346727% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7588 | 6174 | 12 | 12 | 0.16% | 0.19% |  |
| B | 7587 | 6173 | 35 | 35 | 0.46% | 0.57% |  |
| C | 7587 | 6173 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7587 | 6173 | 297 | 297 | 3.91% | 4.81% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 192 | 136839 | 840.58 | 816 | 802 | 161.8 |
| A | 13 | 254 | 8259 | 46.08 | 816 | 802 | 161.8 |
| A | 0 | 226 | 6927 | 37.85 | 816 | 802 | 161.8 |
| B | 7 | 220 | 155525 | 1005.87 | 824 | 806 | 153.8 |
| B | 0 | 182 | 137498 | 888.67 | 824 | 806 | 153.8 |
| B | 0 | 230 | 23888 | 150.06 | 824 | 806 | 153.8 |
| C | 14 | 238 | 124441 | 676.79 | 784 | 793 | 182.7 |
| C | 13 | 61 | 5609 | 26.36 | 784 | 793 | 182.7 |
| C | 0 | 207 | 3732 | 16.09 | 784 | 793 | 182.7 |
| D | 5 | 222 | 1786424 | 9621.31 | 766 | 746 | 185.6 |
| D | 1 | 20 | 619533 | 3334.05 | 766 | 746 | 185.6 |
| D | 1 | 239 | 312204 | 1678.15 | 766 | 746 | 185.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
