| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_009T03_9000003122_21130cztM0_level2.evt | modeM0/AS1A06_009T03_9000003122_21130cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,975,544,640 | 324,550,080 |
| Size | 1.8 GB | 309.5 MB |
| Events in quadrant A | 13,540,468 | 2,104,883 |
| Events in quadrant B | 13,695,293 | 2,118,663 |
| Events in quadrant C | 11,766,957 | 2,045,652 |
| Events in quadrant D | 19,202,134 | 1,901,990 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 55729 | 5 |
| B | 0 | 56086 | 5 |
| C | 0 | 50455 | 6 |
| D | 0 | 73139 | 5 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 44 | 0 |
| B | 0 | 44 | 0 |
| C | 0 | 44 | 0 |
| D | 0 | 44 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 490 | 0 |
| B | 0 | 490 | 0 |
| C | 0 | 490 | 0 |
| D | 0 | 490 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 24116 | 387 | 1.604744% |
| B | 24116 | 595 | 2.467242% |
| C | 24115 | 440 | 1.824591% |
| D | 24115 | 1499 | 6.216048% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 28481 | 24119 | 75 | 75 | 0.26% | 0.31% |  |
| B | 28481 | 24119 | 199 | 199 | 0.70% | 0.83% |  |
| C | 28480 | 24119 | 27 | 27 | 0.09% | 0.11% |  |
| D | 28480 | 24117 | 1198 | 1198 | 4.21% | 4.97% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 192 | 1995914 | 3332.36 | 2986 | 2926 | 598.1 |
| A | 13 | 254 | 36221 | 55.67 | 2986 | 2926 | 598.1 |
| A | 13 | 252 | 30081 | 45.4 | 2986 | 2926 | 598.1 |
| B | 7 | 220 | 773331 | 1369.26 | 2967 | 2892 | 562.7 |
| B | 0 | 182 | 389340 | 686.81 | 2967 | 2892 | 562.7 |
| B | 0 | 228 | 336170 | 592.32 | 2967 | 2892 | 562.7 |
| C | 14 | 238 | 445642 | 666.84 | 2845 | 2862 | 664.0 |
| C | 3 | 233 | 85068 | 123.8 | 2845 | 2862 | 664.0 |
| C | 10 | 91 | 64287 | 92.51 | 2845 | 2862 | 664.0 |
| D | 5 | 222 | 2646520 | 3860.0 | 2828 | 2752 | 684.9 |
| D | 1 | 239 | 1541334 | 2246.39 | 2828 | 2752 | 684.9 |
| D | 1 | 52 | 1288180 | 1876.77 | 2828 | 2752 | 684.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
