| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_009T03_9000003122_21131cztM0_level2.evt | modeM0/AS1A06_009T03_9000003122_21131cztM0_level2_quad_clean.evt |
| Size (bytes) | 477,224,640 | 69,978,240 |
| Size | 455.1 MB | 66.7 MB |
| Events in quadrant A | 3,534,879 | 454,037 |
| Events in quadrant B | 2,963,232 | 464,874 |
| Events in quadrant C | 2,670,883 | 443,728 |
| Events in quadrant D | 4,936,049 | 396,459 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16790 | 2771 |
| B | 0 | 14868 | 2834 |
| C | 0 | 13267 | 2099 |
| D | 0 | 22129 | 3855 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 21 |
| B | 0 | 125 | 21 |
| C | 0 | 125 | 25 |
| D | 0 | 126 | 26 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5151 | 127 | 2.465541% |
| B | 5129 | 73 | 1.423279% |
| C | 5177 | 96 | 1.854356% |
| D | 5105 | 354 | 6.934378% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7522 | 5297 | 57 | 57 | 0.76% | 1.08% |  |
| B | 7524 | 5271 | 10 | 10 | 0.13% | 0.19% |  |
| C | 7528 | 5312 | 16 | 16 | 0.21% | 0.30% |  |
| D | 7524 | 5256 | 272 | 272 | 3.62% | 5.18% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 192 | 934053 | 6887.83 | 674 | 661 | 135.5 |
| A | 13 | 254 | 7489 | 50.39 | 674 | 661 | 135.5 |
| A | 0 | 226 | 6076 | 39.96 | 674 | 661 | 135.5 |
| B | 7 | 220 | 112383 | 865.78 | 675 | 661 | 129.0 |
| B | 0 | 182 | 57973 | 444.13 | 675 | 661 | 129.0 |
| B | 0 | 229 | 28813 | 218.16 | 675 | 661 | 129.0 |
| C | 14 | 238 | 102516 | 675.24 | 642 | 646 | 150.9 |
| C | 0 | 10 | 56374 | 369.39 | 642 | 646 | 150.9 |
| C | 9 | 54 | 8919 | 54.84 | 642 | 646 | 150.9 |
| D | 1 | 52 | 851378 | 5603.19 | 623 | 609 | 151.8 |
| D | 7 | 223 | 695950 | 4579.53 | 623 | 609 | 151.8 |
| D | 1 | 20 | 494634 | 3253.66 | 623 | 609 | 151.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
