| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_009T02_9000003130_21171cztM0_level2.evt | modeM0/AS1A06_009T02_9000003130_21171cztM0_level2_quad_clean.evt |
| Size (bytes) | 351,682,560 | 56,672,640 |
| Size | 335.4 MB | 54.0 MB |
| Events in quadrant A | 2,208,095 | 364,219 |
| Events in quadrant B | 2,177,747 | 367,795 |
| Events in quadrant C | 2,032,534 | 355,576 |
| Events in quadrant D | 3,949,405 | 335,266 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 86 | 0 |
| B | 0 | 86 | 0 |
| C | 0 | 86 | 0 |
| D | 0 | 86 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9366 | 1 |
| B | 0 | 9128 | 1 |
| C | 0 | 8777 | 1 |
| D | 0 | 14601 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4154 | 61 | 1.468464% |
| B | 4154 | 34 | 0.818488% |
| C | 4154 | 40 | 0.962927% |
| D | 4153 | 247 | 5.947508% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 5144 | 4155 | 22 | 22 | 0.43% | 0.53% |  |
| B | 5144 | 4155 | 4 | 4 | 0.08% | 0.10% |  |
| C | 5144 | 4155 | 0 | 0 | 0.00% | 0.00% |  |
| D | 5143 | 4154 | 238 | 238 | 4.63% | 5.73% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 205738 | 1934.81 | 517 | 505 | 106.1 |
| A | 8 | 6 | 7704 | 67.87 | 517 | 505 | 106.1 |
| A | 13 | 254 | 6394 | 55.52 | 517 | 505 | 106.1 |
| B | 0 | 189 | 33830 | 332.3 | 518 | 505 | 100.3 |
| B | 0 | 244 | 30216 | 296.26 | 518 | 505 | 100.3 |
| B | 3 | 64 | 16373 | 158.23 | 518 | 505 | 100.3 |
| C | 14 | 238 | 77200 | 655.8 | 494 | 497 | 117.0 |
| C | 3 | 233 | 26051 | 218.48 | 494 | 497 | 117.0 |
| C | 13 | 61 | 3629 | 26.78 | 494 | 497 | 117.0 |
| D | 1 | 20 | 865964 | 7158.39 | 492 | 477 | 120.9 |
| D | 1 | 52 | 664295 | 5490.4 | 492 | 477 | 120.9 |
| D | 7 | 238 | 217914 | 1798.41 | 492 | 477 | 120.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
