| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_002T01_9000003134_21203cztM0_level2.evt | modeM0/AS1A06_002T01_9000003134_21203cztM0_level2_quad_clean.evt |
| Size (bytes) | 639,567,360 | 90,000,000 |
| Size | 609.9 MB | 85.8 MB |
| Events in quadrant A | 3,204,240 | 659,922 |
| Events in quadrant B | 4,513,295 | 640,423 |
| Events in quadrant C | 3,017,462 | 621,433 |
| Events in quadrant D | 8,222,524 | 378,075 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13427 | 2 |
| B | 0 | 17299 | 1 |
| C | 0 | 12886 | 1 |
| D | 0 | 28559 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6076 | 48 | 0.789993% |
| B | 6077 | 433 | 7.125226% |
| C | 6077 | 64 | 1.053151% |
| D | 6077 | 2310 | 38.012177% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7306 | 6076 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7307 | 6078 | 252 | 252 | 3.45% | 4.15% |  |
| C | 7307 | 6078 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7307 | 6077 | 1813 | 1813 | 24.81% | 29.83% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 11 | 47 | 79004 | 490.01 | 793 | 780 | 159.6 |
| A | 13 | 252 | 36091 | 221.19 | 793 | 780 | 159.6 |
| A | 15 | 236 | 35597 | 218.1 | 793 | 780 | 159.6 |
| B | 0 | 182 | 1373804 | 9453.15 | 771 | 754 | 145.2 |
| B | 0 | 190 | 40536 | 273.89 | 771 | 754 | 145.2 |
| B | 3 | 64 | 40438 | 273.22 | 771 | 754 | 145.2 |
| C | 14 | 238 | 118453 | 684.35 | 739 | 745 | 172.0 |
| C | 3 | 233 | 15078 | 83.33 | 739 | 745 | 172.0 |
| C | 13 | 61 | 5327 | 26.64 | 739 | 745 | 172.0 |
| D | 7 | 238 | 4537546 | 33150.95 | 562 | 545 | 136.9 |
| D | 1 | 52 | 1224269 | 8941.5 | 562 | 545 | 136.9 |
| D | 6 | 143 | 168126 | 1224.48 | 562 | 545 | 136.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
