| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_037T01_9000003140_21236cztM0_level2.evt | modeM0/AS1A05_037T01_9000003140_21236cztM0_level2_quad_clean.evt |
| Size (bytes) | 645,122,880 | 89,928,000 |
| Size | 615.2 MB | 85.8 MB |
| Events in quadrant A | 3,292,080 | 603,863 |
| Events in quadrant B | 3,479,232 | 609,594 |
| Events in quadrant C | 3,215,415 | 591,484 |
| Events in quadrant D | 9,114,940 | 468,694 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13945 | 2 |
| B | 0 | 14475 | 2 |
| C | 0 | 13656 | 2 |
| D | 0 | 31592 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6444 | 84 | 1.303538% |
| B | 6443 | 143 | 2.219463% |
| C | 6443 | 99 | 1.536551% |
| D | 6443 | 1820 | 28.247711% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7574 | 6445 | 4 | 4 | 0.05% | 0.06% |  |
| B | 7573 | 6444 | 53 | 53 | 0.70% | 0.82% |  |
| C | 7573 | 6444 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7573 | 6443 | 1732 | 1732 | 22.87% | 26.88% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 1 | 35302 | 205.95 | 827 | 812 | 167.5 |
| A | 5 | 16 | 31625 | 184.0 | 827 | 812 | 167.5 |
| A | 11 | 47 | 19272 | 110.23 | 827 | 812 | 167.5 |
| B | 0 | 189 | 120690 | 764.16 | 819 | 799 | 156.9 |
| B | 3 | 64 | 60887 | 382.99 | 819 | 799 | 156.9 |
| B | 0 | 190 | 39350 | 245.72 | 819 | 799 | 156.9 |
| C | 14 | 238 | 121994 | 658.92 | 787 | 793 | 183.9 |
| C | 0 | 10 | 23975 | 126.03 | 787 | 793 | 183.9 |
| C | 13 | 61 | 5504 | 25.61 | 787 | 793 | 183.9 |
| D | 1 | 239 | 4950491 | 32695.59 | 622 | 606 | 151.4 |
| D | 13 | 174 | 1301832 | 8595.02 | 622 | 606 | 151.4 |
| D | 7 | 238 | 207399 | 1365.93 | 622 | 606 | 151.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
