| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_037T01_9000003144_21321cztM0_level2.evt | modeM0/AS1A05_037T01_9000003144_21321cztM0_level2_quad_clean.evt |
| Size (bytes) | 488,831,040 | 114,661,440 |
| Size | 466.2 MB | 109.3 MB |
| Events in quadrant A | 3,865,281 | 775,268 |
| Events in quadrant B | 3,402,419 | 789,928 |
| Events in quadrant C | 3,180,512 | 751,183 |
| Events in quadrant D | 3,949,722 | 737,912 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15470 | 1 |
| B | 0 | 13996 | 1 |
| C | 0 | 13225 | 1 |
| D | 0 | 15872 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 120 | 0 |
| B | 0 | 120 | 0 |
| C | 0 | 120 | 0 |
| D | 0 | 120 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5996 | 234 | 3.902602% |
| B | 5996 | 114 | 1.901268% |
| C | 5997 | 116 | 1.934300% |
| D | 5997 | 145 | 2.417876% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7326 | 5996 | 140 | 140 | 1.91% | 2.33% |  |
| B | 7326 | 5996 | 14 | 14 | 0.19% | 0.23% |  |
| C | 7327 | 5997 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7327 | 5997 | 64 | 64 | 0.87% | 1.07% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 236 | 552400 | 3359.2 | 825 | 811 | 164.2 |
| A | 15 | 174 | 45965 | 274.99 | 825 | 811 | 164.2 |
| A | 5 | 16 | 24406 | 143.69 | 825 | 811 | 164.2 |
| B | 3 | 64 | 101465 | 661.29 | 817 | 801 | 152.2 |
| B | 0 | 230 | 28448 | 181.62 | 817 | 801 | 152.2 |
| B | 0 | 197 | 20538 | 129.66 | 817 | 801 | 152.2 |
| C | 14 | 238 | 124115 | 684.37 | 780 | 788 | 180.2 |
| C | 10 | 23 | 6193 | 29.99 | 780 | 788 | 180.2 |
| C | 8 | 222 | 5986 | 28.85 | 780 | 788 | 180.2 |
| D | 1 | 52 | 359010 | 1871.19 | 802 | 781 | 191.4 |
| D | 7 | 38 | 149691 | 777.82 | 802 | 781 | 191.4 |
| D | 12 | 235 | 147404 | 765.88 | 802 | 781 | 191.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
