| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_037T01_9000003144_21325cztM0_level2.evt | modeM0/AS1A05_037T01_9000003144_21325cztM0_level2_quad_clean.evt |
| Size (bytes) | 552,464,640 | 101,439,360 |
| Size | 526.9 MB | 96.7 MB |
| Events in quadrant A | 3,479,785 | 653,550 |
| Events in quadrant B | 4,123,314 | 664,281 |
| Events in quadrant C | 3,452,345 | 641,266 |
| Events in quadrant D | 5,184,992 | 608,982 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15096 | 2 |
| B | 0 | 16919 | 2 |
| C | 0 | 14949 | 2 |
| D | 0 | 20326 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 146 | 0 |
| B | 0 | 146 | 0 |
| C | 0 | 146 | 0 |
| D | 0 | 146 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7242 | 33 | 0.455675% |
| B | 7242 | 220 | 3.037835% |
| C | 7242 | 71 | 0.980392% |
| D | 7242 | 287 | 3.962994% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7637 | 7243 | 2 | 2 | 0.03% | 0.03% |  |
| B | 7637 | 7243 | 121 | 121 | 1.58% | 1.67% |  |
| C | 7637 | 7243 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7637 | 7243 | 188 | 188 | 2.46% | 2.60% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 2 | 30192 | 163.37 | 886 | 867 | 179.5 |
| A | 5 | 168 | 11723 | 60.48 | 886 | 867 | 179.5 |
| A | 13 | 254 | 11665 | 60.15 | 886 | 867 | 179.5 |
| B | 3 | 64 | 500166 | 2947.97 | 879 | 858 | 169.4 |
| B | 0 | 189 | 62774 | 365.56 | 879 | 858 | 169.4 |
| B | 0 | 190 | 55173 | 320.68 | 879 | 858 | 169.4 |
| C | 14 | 238 | 130788 | 656.32 | 846 | 855 | 198.0 |
| C | 3 | 233 | 14128 | 67.05 | 846 | 855 | 198.0 |
| C | 13 | 61 | 6075 | 26.37 | 846 | 855 | 198.0 |
| D | 1 | 20 | 386294 | 1886.5 | 844 | 821 | 204.3 |
| D | 1 | 52 | 369062 | 1802.17 | 844 | 821 | 204.3 |
| D | 12 | 233 | 348242 | 1700.27 | 844 | 821 | 204.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
