| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A06_009T02_9000003152_21364cztM0_level2.evt | modeM0/AS1A06_009T02_9000003152_21364cztM0_level2_quad_clean.evt |
| Size (bytes) | 139,435,200 | 38,160,000 |
| Size | 133.0 MB | 36.4 MB |
| Events in quadrant A | 970,457 | 268,567 |
| Events in quadrant B | 972,671 | 268,526 |
| Events in quadrant C | 1,134,789 | 251,982 |
| Events in quadrant D | 1,036,952 | 251,420 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 30 | 0 |
| B | 0 | 30 | 0 |
| C | 0 | 30 | 0 |
| D | 0 | 30 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3987 | 1 |
| B | 0 | 3978 | 1 |
| C | 0 | 4513 | 3 |
| D | 0 | 4260 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 1558 | 12 | 0.770218% |
| B | 1558 | 24 | 1.540436% |
| C | 1557 | 38 | 2.440591% |
| D | 1557 | 18 | 1.156069% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 1558 | 1558 | 2 | 2 | 0.13% | 0.13% |  |
| B | 1558 | 1558 | 7 | 7 | 0.45% | 0.45% |  |
| C | 1557 | 1557 | 0 | 0 | 0.00% | 0.00% |  |
| D | 1557 | 1557 | 9 | 9 | 0.58% | 0.58% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 96 | 36219 | 738.14 | 235 | 231 | 48.8 |
| A | 5 | 168 | 19458 | 394.36 | 235 | 231 | 48.8 |
| A | 15 | 174 | 3239 | 61.7 | 235 | 231 | 48.8 |
| B | 0 | 230 | 30176 | 678.62 | 228 | 224 | 44.1 |
| B | 0 | 190 | 17395 | 389.04 | 228 | 224 | 44.1 |
| B | 3 | 64 | 16866 | 377.05 | 228 | 224 | 44.1 |
| C | 3 | 233 | 253908 | 4984.25 | 216 | 217 | 50.9 |
| C | 14 | 238 | 35920 | 701.45 | 216 | 217 | 50.9 |
| C | 13 | 61 | 1397 | 23.18 | 216 | 217 | 50.9 |
| D | 12 | 235 | 90515 | 1635.97 | 227 | 221 | 55.2 |
| D | 1 | 52 | 27853 | 500.64 | 227 | 221 | 55.2 |
| D | 7 | 38 | 24775 | 444.88 | 227 | 221 | 55.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
