| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_140T01_9000003160_21397cztM0_level2.evt | modeM0/AS1T03_140T01_9000003160_21397cztM0_level2_quad_clean.evt |
| Size (bytes) | 293,388,480 | 47,554,560 |
| Size | 279.8 MB | 45.4 MB |
| Events in quadrant A | 1,777,799 | 307,393 |
| Events in quadrant B | 1,844,210 | 312,069 |
| Events in quadrant C | 1,988,362 | 300,779 |
| Events in quadrant D | 3,046,611 | 282,018 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 70 | 0 |
| B | 0 | 70 | 0 |
| C | 0 | 70 | 0 |
| D | 0 | 70 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7171 | 1 |
| B | 0 | 7425 | 1 |
| C | 0 | 7965 | 1 |
| D | 0 | 11310 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 3341 | 34 | 1.017659% |
| B | 3341 | 68 | 2.035319% |
| C | 3341 | 98 | 2.933254% |
| D | 3340 | 292 | 8.742515% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 3811 | 3342 | 0 | 0 | 0.00% | 0.00% |  |
| B | 3811 | 3341 | 9 | 9 | 0.24% | 0.27% |  |
| C | 3811 | 3341 | 0 | 0 | 0.00% | 0.00% |  |
| D | 3809 | 3340 | 178 | 178 | 4.67% | 5.33% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 168 | 67051 | 739.1 | 442 | 431 | 90.1 |
| A | 13 | 254 | 5223 | 53.16 | 442 | 431 | 90.1 |
| A | 0 | 226 | 3897 | 38.45 | 442 | 431 | 90.1 |
| B | 0 | 228 | 39029 | 442.9 | 440 | 428 | 87.2 |
| B | 5 | 172 | 20406 | 229.22 | 440 | 428 | 87.2 |
| B | 0 | 189 | 13584 | 150.95 | 440 | 428 | 87.2 |
| C | 3 | 233 | 274287 | 2719.8 | 422 | 424 | 100.7 |
| C | 14 | 238 | 64885 | 640.18 | 422 | 424 | 100.7 |
| C | 13 | 61 | 2928 | 24.87 | 422 | 424 | 100.7 |
| D | 12 | 235 | 984478 | 9586.42 | 420 | 408 | 102.7 |
| D | 1 | 20 | 179506 | 1744.7 | 420 | 408 | 102.7 |
| D | 7 | 38 | 173669 | 1687.84 | 420 | 408 | 102.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
