| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_140T01_9000003160_21417cztM0_level2.evt | modeM0/AS1T03_140T01_9000003160_21417cztM0_level2_quad_clean.evt |
| Size (bytes) | 436,829,760 | 60,546,240 |
| Size | 416.6 MB | 57.7 MB |
| Events in quadrant A | 3,120,729 | 351,242 |
| Events in quadrant B | 3,084,871 | 355,615 |
| Events in quadrant C | 3,081,595 | 345,515 |
| Events in quadrant D | 3,510,322 | 337,340 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13007 | 1 |
| B | 0 | 13082 | 1 |
| C | 0 | 13007 | 1 |
| D | 0 | 14520 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6348 | 23 | 0.362319% |
| B | 6349 | 37 | 0.582769% |
| C | 6349 | 46 | 0.724524% |
| D | 6349 | 120 | 1.890061% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7323 | 6348 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7324 | 6349 | 3 | 3 | 0.04% | 0.05% |  |
| C | 7324 | 6349 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7324 | 6349 | 84 | 84 | 1.15% | 1.32% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 168 | 137686 | 884.64 | 767 | 750 | 154.8 |
| A | 11 | 47 | 22271 | 139.03 | 767 | 750 | 154.8 |
| A | 13 | 254 | 9146 | 54.24 | 767 | 750 | 154.8 |
| B | 0 | 230 | 46931 | 315.69 | 770 | 752 | 146.3 |
| B | 12 | 111 | 17666 | 115.63 | 770 | 752 | 146.3 |
| B | 11 | 111 | 15542 | 101.11 | 770 | 752 | 146.3 |
| C | 14 | 238 | 116787 | 676.76 | 736 | 739 | 171.5 |
| C | 3 | 233 | 48530 | 278.7 | 736 | 739 | 171.5 |
| C | 10 | 91 | 47759 | 274.21 | 736 | 739 | 171.5 |
| D | 13 | 153 | 274691 | 1525.14 | 738 | 718 | 179.6 |
| D | 1 | 52 | 209237 | 1160.78 | 738 | 718 | 179.6 |
| D | 12 | 235 | 95527 | 527.78 | 738 | 718 | 179.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
