| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_117T01_9000003166_21456cztM0_level2.evt | modeM0/AS1A05_117T01_9000003166_21456cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,260,100,800 | 256,296,960 |
| Size | 1.2 GB | 244.4 MB |
| Events in quadrant A | 8,832,977 | 1,644,167 |
| Events in quadrant B | 8,972,131 | 1,663,285 |
| Events in quadrant C | 8,822,246 | 1,597,793 |
| Events in quadrant D | 10,279,192 | 1,578,299 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 378 | 0 |
| B | 0 | 378 | 0 |
| C | 0 | 378 | 0 |
| D | 0 | 378 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 38320 | 4 |
| B | 0 | 38592 | 4 |
| C | 0 | 38450 | 4 |
| D | 0 | 43037 | 4 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 18564 | 244 | 1.314372% |
| B | 18565 | 303 | 1.632103% |
| C | 18565 | 294 | 1.583625% |
| D | 18565 | 282 | 1.518987% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 19949 | 18565 | 0 | 0 | 0.00% | 0.00% |  |
| B | 19950 | 18566 | 8 | 8 | 0.04% | 0.04% |  |
| C | 19950 | 18566 | 0 | 0 | 0.00% | 0.00% |  |
| D | 19950 | 18567 | 116 | 116 | 0.58% | 0.62% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 11 | 47 | 59418 | 126.1 | 2274 | 2228 | 453.5 |
| A | 13 | 254 | 28248 | 57.37 | 2274 | 2228 | 453.5 |
| A | 3 | 137 | 19769 | 38.68 | 2274 | 2228 | 453.5 |
| B | 0 | 197 | 92370 | 207.85 | 2262 | 2204 | 433.8 |
| B | 12 | 111 | 53908 | 119.19 | 2262 | 2204 | 433.8 |
| B | 11 | 111 | 47638 | 104.74 | 2262 | 2204 | 433.8 |
| C | 14 | 238 | 342963 | 677.37 | 2167 | 2184 | 503.1 |
| C | 8 | 128 | 17389 | 30.22 | 2167 | 2184 | 503.1 |
| C | 13 | 61 | 15092 | 25.66 | 2167 | 2184 | 503.1 |
| D | 1 | 52 | 652075 | 1230.01 | 2203 | 2143 | 528.4 |
| D | 14 | 34 | 322595 | 606.46 | 2203 | 2143 | 528.4 |
| D | 12 | 235 | 309903 | 582.44 | 2203 | 2143 | 528.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
