| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A05_117T01_9000003166_21457cztM0_level2.evt | modeM0/AS1A05_117T01_9000003166_21457cztM0_level2_quad_clean.evt |
| Size (bytes) | 597,303,360 | 104,667,840 |
| Size | 569.6 MB | 99.8 MB |
| Events in quadrant A | 3,800,392 | 670,548 |
| Events in quadrant B | 3,838,521 | 678,460 |
| Events in quadrant C | 3,750,960 | 652,144 |
| Events in quadrant D | 6,161,203 | 616,552 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 164 | 0 |
| B | 0 | 164 | 0 |
| C | 0 | 164 | 0 |
| D | 0 | 164 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7 | 0 |
| B | 0 | 7 | 0 |
| C | 0 | 7 | 0 |
| D | 0 | 7 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16490 | 2 |
| B | 0 | 16601 | 2 |
| C | 0 | 16448 | 2 |
| D | 0 | 23826 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7933 | 56 | 0.705912% |
| B | 7934 | 84 | 1.058735% |
| C | 7934 | 88 | 1.109150% |
| D | 7934 | 585 | 7.373330% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8693 | 7934 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8693 | 7934 | 0 | 0 | 0.00% | 0.00% |  |
| C | 8694 | 7934 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8694 | 7935 | 534 | 534 | 6.14% | 6.73% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 11 | 47 | 54407 | 272.52 | 971 | 950 | 196.2 |
| A | 13 | 254 | 10370 | 48.02 | 971 | 950 | 196.2 |
| A | 3 | 137 | 8364 | 37.8 | 971 | 950 | 196.2 |
| B | 0 | 197 | 37793 | 194.2 | 966 | 941 | 189.8 |
| B | 12 | 111 | 23420 | 118.46 | 966 | 941 | 189.8 |
| B | 11 | 111 | 20771 | 104.5 | 966 | 941 | 189.8 |
| C | 14 | 238 | 146051 | 667.51 | 924 | 931 | 217.4 |
| C | 13 | 61 | 6390 | 25.11 | 924 | 931 | 217.4 |
| C | 8 | 128 | 2468 | 7.07 | 924 | 931 | 217.4 |
| D | 12 | 235 | 2082113 | 9367.24 | 919 | 893 | 222.2 |
| D | 14 | 34 | 206038 | 923.33 | 919 | 893 | 222.2 |
| D | 5 | 222 | 117645 | 525.48 | 919 | 893 | 222.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
