| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_141T01_9000003174_21479cztM0_level2.evt | modeM0/AS1T03_141T01_9000003174_21479cztM0_level2_quad_clean.evt |
| Size (bytes) | 477,403,200 | 73,419,840 |
| Size | 455.3 MB | 70.0 MB |
| Events in quadrant A | 3,300,887 | 453,429 |
| Events in quadrant B | 3,402,947 | 463,443 |
| Events in quadrant C | 3,367,971 | 451,730 |
| Events in quadrant D | 3,973,747 | 429,820 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 19 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13526 | 0 |
| B | 0 | 13861 | 0 |
| C | 0 | 13821 | 0 |
| D | 0 | 15598 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6085 | 80 | 1.314708% |
| B | 6085 | 109 | 1.791290% |
| C | 6085 | 145 | 2.382909% |
| D | 6085 | 213 | 3.500411% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7360 | 6085 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7360 | 6085 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7360 | 6085 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7360 | 6085 | 143 | 143 | 1.94% | 2.35% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 9215 | 50.01 | 856 | 842 | 167.4 |
| A | 0 | 226 | 7391 | 39.11 | 856 | 842 | 167.4 |
| A | 3 | 137 | 6275 | 32.45 | 856 | 842 | 167.4 |
| B | 0 | 230 | 33612 | 209.14 | 854 | 835 | 156.7 |
| B | 0 | 190 | 25650 | 158.34 | 854 | 835 | 156.7 |
| B | 12 | 111 | 17736 | 107.84 | 854 | 835 | 156.7 |
| C | 14 | 238 | 134865 | 716.17 | 826 | 837 | 187.1 |
| C | 3 | 233 | 14221 | 71.52 | 826 | 837 | 187.1 |
| C | 13 | 61 | 5844 | 26.75 | 826 | 837 | 187.1 |
| D | 1 | 52 | 230276 | 1160.05 | 830 | 811 | 197.8 |
| D | 13 | 172 | 153128 | 770.03 | 830 | 811 | 197.8 |
| D | 7 | 38 | 151458 | 761.59 | 830 | 811 | 197.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
