| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T03_141T01_9000003174_21488cztM0_level2.evt | modeM0/AS1T03_141T01_9000003174_21488cztM0_level2_quad_clean.evt |
| Size (bytes) | 904,668,480 | 177,917,760 |
| Size | 862.8 MB | 169.7 MB |
| Events in quadrant A | 6,033,936 | 1,132,764 |
| Events in quadrant B | 6,360,275 | 1,153,717 |
| Events in quadrant C | 6,092,785 | 1,122,138 |
| Events in quadrant D | 8,021,073 | 1,071,853 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 26766 | 0 |
| B | 0 | 27398 | 0 |
| C | 0 | 26739 | 0 |
| D | 0 | 32878 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 270 | 0 |
| B | 0 | 270 | 0 |
| C | 0 | 270 | 0 |
| D | 0 | 270 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 13141 | 43 | 0.327220% |
| B | 13141 | 85 | 0.646831% |
| C | 13142 | 85 | 0.646781% |
| D | 13142 | 402 | 3.058895% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 14946 | 13141 | 0 | 0 | 0.00% | 0.00% |  |
| B | 14946 | 13142 | 22 | 22 | 0.15% | 0.17% |  |
| C | 14947 | 13143 | 0 | 0 | 0.00% | 0.00% |  |
| D | 14947 | 13144 | 348 | 348 | 2.33% | 2.65% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 19912 | 58.38 | 1564 | 1532 | 314.8 |
| A | 0 | 226 | 13573 | 38.25 | 1564 | 1532 | 314.8 |
| A | 3 | 137 | 13264 | 37.26 | 1564 | 1532 | 314.8 |
| B | 0 | 190 | 76229 | 250.6 | 1565 | 1527 | 298.1 |
| B | 0 | 230 | 75053 | 246.66 | 1565 | 1527 | 298.1 |
| B | 3 | 64 | 53056 | 172.86 | 1565 | 1527 | 298.1 |
| C | 14 | 238 | 236597 | 666.06 | 1501 | 1512 | 352.9 |
| C | 13 | 61 | 10462 | 25.36 | 1501 | 1512 | 352.9 |
| C | 3 | 233 | 8111 | 18.7 | 1501 | 1512 | 352.9 |
| D | 1 | 52 | 811974 | 2065.09 | 1481 | 1453 | 392.5 |
| D | 5 | 222 | 647086 | 1644.98 | 1481 | 1453 | 392.5 |
| D | 7 | 38 | 644013 | 1637.15 | 1481 | 1453 | 392.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
